• Model NO.：P6
• Pixel Density：27777dots,Sq.M
• Scanning Mode：1,8 Scan
• Display Type：LED Video Display
• Application：Advertising, Stage Performance, Rental
• Certification：CE, RoHS, CCC
• LED Encapsulation：SMD3535
• Module Size：192X192mm
• Module Resolution：32X32dots
• Cabinet Size：768X768mm
• Transport Package：Flight Case or Wooden Case
• Specification：CE, FCC. ROHS, 3C
• Trademark：PRT
• Origin：Shenzhen China
• HS Code：8528591090
• Production Capacity：3000sq. M,Month

P6 SMD3535 Outdoor full Color LED Screen SpecificationPixel pitch6mmPixel Configuration1R1G1BLED componentSMD3535Size of module192x192mmResolution of module64 x 64Size of cabinet768mm x 768mm x 150mm / 960 x 960x150mmResolution of cabinet128x128/ 160x160Material of CabinetIron/ AluminumWeight of Cabinet40kgs for iron cabinetBrightness>6000cd/m2Density27777dots/m2Best viewing angle140 /140Pixel Configuration1R1G1BBest viewing distance5-60MMaximum power consumption900W/m2Average power consumption560W/m2Driving method1/8 scanControl methodSynchronizationGray scale65536Colors256*256*256Color temperature3200-9300kUniformity97%Working voltageAC220V/110V±10%Working temperature-20ºC~+50ºC±10%Working humidity10% ~ 90%MTBF10,000 hoursFrame frequence50/60HzRefresh frequence>1920HzIP gradeIP65Life Span100,000 hoursData transafer methodRJ45Pratical standardCCC  TUV-CE  ETL etc.Effectivce Communication
Distance(without relay)Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KMAccepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.Systems operating platformWINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development We provide two years warranty normally,also can three years according to customer's request,and keep after-sale service and free maintenance for lifetime,only ask for material costs,and our products produced based on international standards and got certifications,so we can ensure the high quality and long life span
