Pump Bearing
Fujian Dehua Hengyuan Ceramics Co., Ltd.- Rolling Body：Ball Bearings
- Separation：No
- The Number of Rows：Single
- Outer Dimension：Small and Medium-Sized(60-115mm)
- Load Direction：Radial Bearing
- Material：Bearing Steel
Base Info
- Max Runout Speed：Grease Rpm: 11000 Oil Rpm: 13000
- Precision Rating：Po,P6
- Noise Level：Z1,Z2,V1,V2,V3,V4
- Export Markets：Global
- Transport Package：Plastic Bag + Color Box + Cartocarton) + Plywood
- Specification：ISO9001
- Trademark：NSK-TIMKEN-OEM-KOYO
- Origin：China Japan Germany Sweden America
- HS Code：84821000
- Production Capacity：50000000PCS,Month
Description
Bearing Model No.Bore O.D Width Load rating Ball Complement Limiting Speed KN d D B Dynamic Cr. Static Cor. No. size grease oil mm in. mm in. mm in. Cr Cor mm r/min r/min 604 4 0.1575 12 0.4724 4 0.1575 0.96 0.35 7 2.381 36000 45000 605 5 0.1969 14 0.5512 5 0.1969 1.07 0.42 7 2.381 30000 38000 606 6 0.2362 17 0.6693 6 0.2362 1.96 0.73 6 3.969 30000 38000 607 7 0.2756 19 0.7480 6 0.2362 2.80 1.06 6 3.969 28000 36000 608 8 0.3150 22 0.8661 7 0.2756 3.29 1.36 7 3.969 26000 34000 609 9 0.3543 24 0.9449 7 0.2756 3.33 1.41 7 3.969 22000 30000 624 4 0.1575 13 0.5118 5 0.1969 1.15 0.40 6 2.381 36000 45000 625 5 0.1969 16 0.6299 5 0.1969 1.88 0.68 6 3.175 32000 40000 626 6 0.2362 19 0.7480 6 0.2362 2.80 1.06 6 3.969 30000 38000 627 7 0.2756 22 0.8661 7 0.2756 3.29 1.36 7 3.969 28000 36000 628 8 0.3150 24 0.9449 8 0.3150 3.33 1.41 7 3.969 24000 32000 629 9 0.3543 26 1.0236 8 0.3150 3.20 1.47 7 4.500 22000 33000 634 4 0.1575 16 0.6299 5 0.1969 1.88 0.68 7 3.175 32000 40000 635 5 0.1969 19 0.7480 6 0.2362 2.81 1.06 6 3.969 30000 36000 636 6 0.2362 22 0.8661 7 0.2756 3.29 1.36 7 3.969 30000 36000 637 7 0.2756 26 1.0236 9 0.3543 3.34 1.41 7 3.969 28000 34000 638 8 0.3150 28 1.1024 9 0.3543 4.16 1.78 7 4.763 28000 34000 639 9 0.3543 30 1.1811 10 0.3937 5.12 2.39 8 4.763 24000 30000 684 4 0.1575 11 0.4331 3 0.1181 0.55 0.25 9 1.588 35000 45000 685 5 0.1969 11 0.4331 3 0.1181 0.33 0.40 9 1.588 33000 40000 686 6 0.2362 13 0.5118 3.5 0.1378 0.90 0.46 8 2.000 31000 38000 687 7 0.2756 14 0.5512 3.5 0.1378 1.38 0.71 9 2.000 29000 36000 688 8 0.3150 16 0.6299 4 0.1575 1.38 0.71 9 2.381 28000 32000 689 9 0.3543 19 0.7480 5 0.1969 1.40 0.75 9 2.381 26000 30000 694 4 0.1575 11 0.4331 4 0.1575 0.96 0.35 8 2.000 48000 56000 695 5 0.1969 13 0.5118 4 0.1575 1.07 0.42 8 2.000 43000 50000 696 6 0.2362 15 0.5906 5 0.1969 1.47 0.60 8 2.381 40000 45000 697 7 0.2756 17 0.6693 5 0.1969 1.60 0.71 8 2.381 36000 43000 698 8 0.3150 19 0.7480 6 0.2362 2.23 0.91 7 3.500 36000 43000 699 9 0.3543 20 0.7874 6 0.2362 2.48 1.09 9 2.381 34000 40000 6000 10 0.3937 26 1.0236 8 0.315 4.55 1.95 7 4.763 29000 34000 6001 12 0.4724 28 1.1024 8 0.315 5.10 2.39 8 4.763 26000 30000 6002 15 0.5906 32 1.2598 9 0.3543 5.60 2.84 9 4.763 22000 26000 6003 17 0.6693 35 1.3780 10 0.3937 6.80 3.35 10 4.763 20000 24000 6004 20 0.7874 42 1.6535 12 0.4724 9.40 5.05 9 6.350 18000 21000 6005 25 0.9843 47 1.8504 12 0.4724 10.10 5.85 10 6.350 15000 18000 6006 30 1.1811 55 2.1645 13 0.5118 13.20 8.30 11 7.144 13000 15000 6007 35 1.3779 62 2.4409 14 0.5512 16.00 10.30 11 7.938 12000 14000 6008 40 1.5748 68 2.6772 15 0.5906 16.80 11.50 12 7.938 10000 12000 6009 45 1.7716 75 2.9528 16 0.6299 21.00 15.10 12 8.731 9200 11000 6010 50 1.9650 80 3.1496 16 0.6299 21.80 16.60 13 8.731 8400 9800 6011 55 2.1653 90 3.5433 18 0.7087 28.30 21.20 12 11.000 7700 9000 6012 60 2.3620 95 3.7400 18 0.7087 29.50 23.20 13 11.000 7000 8300 6013 65 2.5590 100 3.9370 18 0.7087 30.50 25.20 13 11.112 6500 7700 6014 70 2.7559 110 4.3307 20 0.7874 38.00 31.00 13 12.303 6100 7100 6015 75 2.9528 115 4.5276 20 0.7874 39.50 33.50 14 12.303 5700 6700 6016 80 3.1496 125 4.9213 22 0.8661 47.50 40.00 14 13.494 5300 6200 6017 85 3.3465 130 5.1181 22 0.8661 49.50 43.00 14 14.000 5000 5900 6018 90 3.5433 140 5.5118 24 0.9449 58.00 49.50 14 15.080 4700 5600 6019 95 3.7402 145 5.7087 24 0.9449 60.50 54.00 14 15.080 4500 5300 6020 100 3.9370 150 5.9055 24 0.9449 60.00 54.00 14 16.000 4200 5000 6200 10 0.3973 30 1.1811 9 0.3543 5.10 2.39 8 4.763 25000 30000 6201 12 0.4724 32 1.2598 10 0.3937 6.10 2.75 7 5.953 22000 26000 6202 15 0.5906 35 1.3779 11 0.4331 7.75 3.60 8 5.953 19000 23000 6203 17 0.6693 40 1.5748 12 0.4724 9.60 4.60 8 6.747 18000 21000 6204 20 0.7874 47 1.8504 14 0.5512 12.80 6.65 8 7.938 16000 18000 6205 25 0.9843 52 2.0472 15 0.5906 14.00 7.85 9 7.938 13000 15000 6206 30 1.1811 62 2.4409 16 0.6299 19.50 11.30 9 9.525 11000 13000 6207 35 1.3779 72 2.8346 17 0.6693 25.70 15.30 9 11.112 9800 11000 6208 40 1.5748 80 3.1496 18 0.7087 29.10 17.80 9 12.000 8700 10000 6209 45 1.7716 85 3.3465 19 0.748 32.50 20.40 10 12.000 7800 9200 6210 50 1.9650 90 3.5433 20 0.7841 35.00 23.20 10 12.700 7100 8300 6211 55 2.1653 100 3.9370 21 0.8268 43.50 29.20 10 14.288 6400 7600 6212 60 2.3620 110 4.3307 22 0.8661 52.50 36.00 10 15.081 6000 7000 6213 65 2.5590 120 4.7244 23 0.9055 57.50 40.00 10 16.669 5500 6500 6214 70 2.7559 125 4.9213 24 0.9449 62.00 44.00 11 16.669 5100 6000 6215 75 2.9528 130 5.1181 25 0.9843 66.00 49.50 11 17.462 4800 5600 6216 80 3.1496 140 5.7087 26 1.0236 72.50 53.00 11 18.256 4500 5300 6217 85 3.3465 150 5.9055 28 1.1024 83.50 64.00 11 19.844 4200 5000 6218 90 3.5433 160 6.2992 30 1.1811 96.00 71.50 10 22.225 4000 4700 6219 95 3.7402 170 6.6929 32 1.2598 109.00 82.00 10 24.000 3700 4400 6220 100 3.9370 180 7.0866 34 1.3386 122.00 93.00 10 25.400 3500 4200
