• Model NO.：indoor P1.667 LED board
• System Operating Platform：Windows XP , Windows 7 , Windows 8 ,8.1
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP43
• Certification：CE, RoHS, CCC, ISO9001 ISO14001 FCC
• Product Name：P1.6 Indoor LED Display
• Driver IC：Mbi5153 or Icn 2153
• Bightness CD/Sq：900CD
• Warranty：3 Years Warranty
• Life Time：More 100,000 Hours (80%)
• Mtbf：More 50,000 Hours
• Operating Temperature：-30~-60t
• Cabinet Size：400mmx300mmx75
• Transport Package：Wooden Case, Flight Case and Carton
• Specification：CE 3C ROHS FCC ISO: 9001 ISO: 14001
• Trademark：HONGKING
• Origin：Shenzhen China
• HS Code：8528591090
• Production Capacity：5000sqm,Year

Basic Info.

Model NO. indoor P1.667 LED board System Operating Platform Windows XP / Windows 7 / Windows 8 /8.1 Display Type LED Video Display Application Stage Performance, Advertising, Shopping Guide IP Rating IP43 Certification CE, RoHS, CCC, ISO9001 ISO14001 FCC Product Name P1.6 Indoor LED Display Driver IC Mbi5153 or Icn 2153 Bightness CD/Sq 900CD Warranty 3 Years Warranty Life Time More 100,000 Hours (80%) Mtbf More 50,000 Hours Operating Temperature -30~-60t Cabinet Size 400mmx300mmx75 Transport Package Wooden Case, Flight Case and Carton Specification CE 3C ROHS FCC ISO: 9001 ISO: 14001 Trademark HONGKING Origin Shenzhen China HS Code 8528591090 Production Capacity 5000sqm/Year

Product Description

P1.6 P1.5 P1.25 LED Display screen Panel for Advertising

 1. If you have interests in buying, pleased send A complete inquiry need to show:
      1. led screen panel pixel pitch, if you dont know how to choose, contact us
      2. led screen size:length ___m; width___m,or cabinet quantity;
      3. use for indoor or outdoor;  fixed installation or rental?
     4. intallation place pictures will be better;

• Contact person : Phebe
• Mobile phone: 00 86 177 2460 2807



model	P1.562	P1.667
Pixel Pitch	1.562mm	1.667mm
Unit Size	400mmx300mmX75	400mmx300mmX75
LED Type	SMD1010	SMD1010
Pixel / Unit	256*192	240*180
Unit Weight	4.6Kg	4.6kg
Viewing Angle	H140 degree V140 degree	H140 degree V140 degree
Application	Storage-40°~60° C, working-20°~50° C,	Storage-40~60° C,   Working-20~50° C
Protection Level	For indoor use only	For indoor use only
Power Consumption	700W/sqm	750W/sqm
Driving	1/32 scan	1/30 Scan
Frame Refresh	≥ 60Hz	≥ 60Hz
Refresh Rate	>1920Hz	>1920Hz
Processing	16bit	16bit
Brightness	800nits	800nits
Power Supply	AC110/240V, 50~60Hz	AC110/240V, 50~60Hz
MTBF	≥ 1, 000 Hours	≥ 1, 000 Hours
Life Span	≥100, 000 Hours	≥ 100, 000 Hours
Pixel Failure	< 0.0003	< 0.0003

Payment term: T/T , usually 30~50% down payment before production,balance to be paid before delivery
Delivery time:Production lead time less 20 sqm is about 8-12 working days, more than 50 sqm. is about 15 working days
Free sample or not: Sample is available,but need to pay the material cost and freight cost
MOQ: 1 sqm for led screen,and 1pcs for led module
Guarantee:3 years quality guarantee,after 3 years,we will ask for material cost only,customer pay freight cost

hongking  always provide high quality products to our customers,and good after-sale service,obtained a good reputation,we produce our products based on international standards FCC,CE,RoHs,and with a strict quality control system,and confirm 2 to 3 years warranty,during this period,we will repair the default parts with free of charges,after the period,and during the lifetime,we only ask for material costs.


Why choose  HONGKING?

    HONGKING is a professional manufacturer of LED display screens over 6 years. We have strong R&D to ensure high end products with user-friendly design .
    The prices are very competitive due to our large-scale procurement of raw material.   We can help you to win more orders if you are distributors.End users will also be satisfied with our quality and price.
    We have CE, FCC and Rohs certificates. Our products are exported over 85 countries .We have rich experience in handling all possible problems when you import goods from China .
    We have a wide variety of products for you to choose from .All products are strictly tested before release to market and we test every LED screen 72 hours before delivery.
    Our sales are well trained to offer professional advice on your specific projects. Processional engineers are on standby, can offer guidance, on site technical support as requested.
    We offer 2-3 years warranty and life time maintenance .Even when warranty time expires , we only charge material costs
