Car Polish Station, with Basement
Luminous Optical Technology Co., Ltd.- Airflow Direction：Lateral Undershot-type
- Paint Mist Treatment：Dry-type
Base Info
- Product Name：Car Polish Station
- Usage：Car(or Furniture) Polish,Painting
- Color：Customize Acceptable
- Certificate：CE,CCS,TUV,SGS
- Service：Professional Engineer Team for Install
- Warranty：1 Year
- Transport Package：3PCS,20gp
- Specification：CE, CCS, TUV, SGS
- Trademark：Baoyues
- Origin：China
- HS Code：84198990
- Production Capacity：90units,Month
Description
| Item | Detailed Specification |
| Outside Dimension | 7550×3550×3100mm(L×W×H) |
| Inside Dimension | 6300×3450×2650mm(L×W×H) |
| Plenum Dimension | 6300×3450×450mm(L×W×H) |
| Basement | 300mm galvanized steel basement, full grilles made by flat bar and twisted steel then galvanized. 2 ramps, external setting, 2000×750mm(L×W), surface is painted. |
| Room Body | Back side with 50mm EPS wallboard, the other 3 sides with PVC curtains; |
| Light System | Ceiling lights 8units×4pcs=32pcs×36W, with electronic ballasts |
| Generator Cabinet | Exhaust from rear side; square steel frame, galvanized steel cover. |
| Intake and Exhaust System | 1 unit 5.5KW double intake centrifugal fan, model YDW-4.5S, air capacity: 15500 m 3/h, electric damper for exhausting. |
| Purification System | Pre-filter, high efficiency filter, exhaust fiberglass filter |
| Roof | Galvanized steel plates |
| Control System | Fan operation switch, lighting switch, emergency stop; |
| Install way | Suspending steel hook from roof of building or steel column supporting; |
| Total Power | 6.7KW |
