Car Prep Station Room with High Quality
Jiaxing Topaz Import & Export Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Preparation
- Certification：CE
- Substrate：Steel
- Brand：Longxiang Brand
Base Info
- Model NO.：LX-6100
- Coating：Powder Coating
- Airflow Direction：Cross-flow Type
- Heating Mode：Without Heating
- Paint Mist Treatment：Dry-type
- Condition：New
- Inside Dimension：6300*3450*2800mm(L*W*H)
- Outside Dimension：7550*3550*3200mm(L*W*H)
- Basement：Without Basement
- Fan System：Centrifugal Fan
- Lighting System：LED Lighting
- Voltage：380V,220V
- Total Power：6.4kw
- Usage：Car Polishing
- Name：Prep Station
- Filtering System：Fiber Glass Filter
- Transport Package：Sea Package
- Specification：7550*3550*3200mm(L*W*H)
- Trademark：longxiang brand
- Origin：China
- HS Code：8419899090
- Production Capacity：30 Sets,Months
Description
Specification of Prep-station (LX-6100) Inside dimension6300×3450×2800mm(L×W×H)Outside dimension7550×3550×3200mm(L×W×H)Basement and floorWithout basementCeiling system6400×3550×520mm(L×W×H),with coaming all sides,lighting between the coaming along the length.The back section of the ceiling is sealed by seal plateGenerator setting typeRear exhaust;square tube frame;white color coated steelExhaust systemGenerator cabin dimension:2290×1200×1800mm(L×W×H);5.5KW one set inner motor centrifugal fan with air capacity 16000m³/h,belt-drive,electric damper to control the air inlet and outlet volumeSeal typeBack side set 50mm EPS,other 3 sides with PVC soft curtain,curtain color:upper part:white,middle part:transparent,lower part:whiteCeiling installationSteel rope hanging or steel pole supporting the roof(optional)Filter systemFiberglass filterLighting system8 units×3pcs=24×36W;side lightsControl systemFan switch,lighting switch and electric damper switchVoltage frequency380V/3PH or 220V/1PH,50HZTotal power 6.4KW
