Constant Current Drive Text Fws P5 Module Outdoor LED Display
Emoer Industry Limited- Tube Chip Color：Full Color
- IP Rating：IP43
- Pixel Pitch：3mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display, Image & Text Display, Text Display, Market Display
- Average Power Consumption：300W , m²
Base Info
- Model NO.：P3
- Pixel Density：111111 Dots,Sqm
- Scanning Mode：1,16 Scan
- Display Type：LED Video Display
- Application：Stage Performance
- Certification：CE, RoHS, UL, CCC, ETL
- Deliver Time：15-20 Days
- Warranty Period：3 Years
- Packing Method：Premier Cardboard and Natural Packing
- Pixel Structure：SMD LED 1921 3 in 1
- Module Size：192*192mm
- Driver Type：Constant Current Drive
- Mtbf：10000h
- Average Lifetime：50000h
- Brightness：>3500nits
- Refresh Rate：>1920Hz
- Waterproof Rating：IP43
- Best Visual Distance：3-30m
- Maintenance Method：Maintained From The Front , Back
- Grayness：4096-65536 Adjustable
- Working Temperature/Humidity：-10-40 , 10%-70%Rh
- Transport Package：Cardboard Box, Wooden Carton and Fright Case
- Specification：960 mm*960 mm
- Trademark：FWS
- Origin：Shenzhen China
- HS Code：8528591090
- Production Capacity：25000sqm, Month
Description
LED ModuleLED CabinetPixel Density111,111 Dots/sqmCabinet Resolution256 ×256 = 65536 (Dots)Cabinet Dimension(W*H*D)960mm × 960mm × 120mmModule Quanty /Cabinet5×5=25(Pcs)Color Grayscale16bitCabinet WeightControl SystemInput SignalAVI/MPG/MPEG/TXT.etcControl SystemSending Card, Receiving Card, Receiving HUBPC Operating SystemMicrosoft Windows 10, Windows 7, and XPSoftwareLED Studio ( FWS-linen )Communication TypeNet cable: 3G, WIFI(Sold separately)LanguageChinese, Traditional Chinese, English, French, Japanese, Russian, Thai, Spanish, Polish, Italian, Portuguese, Turkish, Dutch, Greek, Bulgarian, Romanian, Arabic, Korean, German CertificateCE, ROHS, FCC, ISO9001, TUVControl Card InputDVI, USB; RJ45, HDMI(Sold separately)
Trade Terms
1). Payment: T/T, usually 50% prepayment before production, 50% balance to be paid before delivering.
2). Production lead time less than 100 sqm: 15-20 days, more than 200 sqm: 30days.
4). Shipping port: Shenzhen, Mainland China.5). Discounts are offered based on order quantities
Clients
FAQ;
Q1; Do you have any MOQ limit for LED display orders?
Trade Terms1). Payment: T/T, usually 50% prepayment before production, 50% balance to be paid before delivering.
2). Production lead time less than 100 sqm: 15-20 days, more than 200 sqm: 30days.
4). Shipping port: Shenzhen, Mainland China.5). Discounts are offered based on order quantities
