P5.95 Outdoor Full Color LED Display Screen for Sports Perimeter
Xuzhou Whuchan Co., Ltd- Tube Chip Color：Full Color
- IP Rating：IP65
- Pixel Pitch：5.95mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display
- Average Power Consumption：300W , m²
Base Info
- Model NO.：P5.95-outdoor
- Pixel Density：28224dots,Sq.M
- Scanning Mode：1,7 Scan
- Display Type：LED Video Display
- Application：Stage Performance, Advertising,Rental
- Certification：CE, RoHS, ETL
- Type of LEDs：SMD3535
- Panel Size：500X500mm
- Panel Resolution：84X84 Dots
- Module Size：250X250mm
- Transport Package：Flight Case or Wooden Case
- Specification：CE, ROHS, FCC, ETL
- Trademark：PRT
- Origin：Shenzhen China
- HS Code：8528591090
- Production Capacity：3000sq. M,Month
Description
P5.95 Outdoor full Color LED Screen SpecificationPixel pitch 5.95mm Pixel Configuration 1R1G1B LED component SMD3535 Size of module 250mm x 250mm Resolution of module 42x42dots Size of cabinet 500x500mmx75mm /500 x 1000 x 75mm Resolution of cabinet 84x84/84x168dots Material of Cabinet Die-casting Aluminum/Aluminum profile Weight of Cabinet 8kgs/ 13.80KGS Brightness >5500cd/sq.m Density 28224dots/sq.m Best viewing angle 140 /140 Pixel Configuration 1R1G1B Best viewing distance 6-100M Maximum power consumption 1000W/sq.m Average power consumption 550W/sq.m Driving method 1/7 scan Control method Synchronization Gray scale 65536 Colors 256*256*256 Color temperature 3200-9300k Uniformity 97% Working voltage AC220V/110V±10% Working temperature -20ºC~+50ºC±10% Working humidity 10% ~ 90% MTBF 10,000 hours Frame frequence 50/60Hz Refresh frequence >1920Hz IP grade IP65 Life Span 100,000 hours Data transafer method RJ45 Pratical standard CCC TUV-CE ETL etc. Effectivce Communication
Distance(without relay) Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
Distance(without relay)
Single-mode optic fiber: 10KM
