6000CD P8 Outdoor LED Display Module (256*128mm)

Freezer Spacer
  • Tube Chip Color：Full Color
  • IP Rating：IP65
  • Pixel Pitch：8 mm
  • Pixel Configuration：SMD3535
  • Display Function：Video Display, Image & Text Display, Text Display, Market Display
  • Average Power Consumption：400W,M2

Base Info

  • Model NO.：P8 LED module
  • Pixel Density：15625 DOT,M2
  • Scanning Mode：1,4 S
  • Display Type：LED Video Display
  • Application：Advertising
  • Certification：CE, RoHS, UL, CCC, FCC
  • LED Lamp：Nation Star,Kinglight
  • Scan：1,4 S
  • Warranty：2-5 Years
  • Brightness：5500-7000 CD ,M2
  • Module Size：256*128 mm
  • Maintenance Mode：Front , Back
  • Production Time：5-12 Working Days
  • IP Grade：IP 65
  • Use Voltage：AV 220,110V
  • Display Size：5*4m, 6*4m, 10*8m, 8*6m
  • Maximum Power Consumption：800W,M2
  • Module Resolution：32*16
  • Transport Package：Carton
  • Specification：256*128mm, 320*160 mm
  • Trademark：HONGHUI
  • Origin：Shenzhen, China
  • HS Code：85312000
  • Production Capacity：5000 PCS ,Day

Description

            1Pixel Pitch 8 mm 2Cabinet Size 1024*1024 mm/768*768mm3Pixel density 15,625 dots/m2 4Color temperature6000K--8000K5Viewing angleH:140;V:1406Dead LED lamp rate≤0.1‰7Non-Flatness<0.2mm8Module interval<0.2mm9Packaging Gross Weight(KG)45 kg (Estimated data)10Packaging dimension1m*1m*1.15 m (6cabinet in one case)11Maximal power/m2 1000 W/m212Brightness adjusted256 grade by auto-optic/color &8 grade by hand13Input signalRF,S-video,RGB,RGBHV,YUV,YC&Composition,etc14Life-span ≥1 00,000 hours15MTBF 5,000 hours16Frame frequency25 - 60 Hz / s17Refresh rate≥2,000 Hz  / s18Signak Input(with video processor)HDMI, DVI, VGA, RF, S-Video, RGB,
RGBHV, YUV, YC&Composition, etc.19Control Distance120 m (no repeating); Optical fiber
transmission: 0.5km- 10km20Systems Operating PlatformWindows XP, Win 7, Win8, Win8.1, Win10A96 Hours Serious Testing Time B72 Hours Display Testing TimeC24 Hours Module Testing Time D24 Hours After-sales online Service E12 Hours  LED Inquiry Response TimeF8 years Professional LED display factory G5 years Excellent Domestic Big Government LED Designer H3 years Expanding International  Trade ExperienceQ1:Are you a factory or just a trade company?
A1:Our HONGHUI is a led display factory with R&D department and production line,professional engineering team and energetic sales team.Warmly welcome to visit our HONGHUI factory and have face-to-face business talk to better understand each other .Or when you are free ,we can have SKYPE VIDEO TALKING ,and show our HONGHUI factory.

Q2:Can you tell me why I should choose your company ?
A2:Concentration makes professional .Professional achieves successful .
Our HONGHUI have 8 years professional led technical experience .We are 5 years gold supplier for China government led project .Now ,we are largely expanding our international market.From 2009 to 2017, we only do LED .Now and In the future, we still do LED.We can cooperate from trail order to establish trust step by step .

Q3: What's the warranty of your LED Display ?
A3: 2-5 years warranty .and 96360hours life span.During the warranty period ,we can offer you related after-sales service. Our professional engineering team are ready for your question during 6:00-23:30.
