• Model NO.：ZGSM-LD80H4
• Charging Time (H)：6
• Usage：Garden, Street, Roadway, Urban Road, Branch Road, Highway, and Ect
• IP Rating：IP66
• Certification：CE, RoHS
• Voltage：12,24V
• With Light Source：With Light Source
• LED Luminous Source：Lumileds Luxeon Tx
• Maximum Current：DC 4.63 -24V
• Battery：Lead Acid, or Gel Battery
• Lens：Type 1m, 2m, 3m, or 5s
• Driver Efficiency：> 90%
• Transport Package：1PC, Carton
• Specification：CE, RoHS, SAA
• Trademark：ZGSM or OEM
• Origin：China
• HS Code：94055000
• Production Capacity：20, 000PCS,Set

ModelZGSM-35HZGSM-80H4ZGSM-100HWorking Voltage12V DC24V DC24V DCSystem's Power35W80W100WLumen Output3675 lm9600 lm10500 lm
Battery Technical DateSystem's Power35W80W100W100HAMax 24hsMax 25 hoursMax 16 hours150HAMax 36hsMax 38 hoursMax 25 hours200HAMax 48hsMax 51 hoursMax 33 hours300HAMax 72hsMax 77 hoursMax 50 hours

Solar Panel Technical Data(12 hours working per day)System's Power35W80W100WCoefficient: 3hourssolar panel 200Wsolar panel: 400Wsolar panel: 500WCoefficient: 4hourssolar panel: 150Wsolar panel: 300Wsolar panel: 400WCoefficient: 5hourssolar panel: 150Wsolar panel: 200Wsolar panel: 300WCoefficient: 6hourssolar panel: 100Wsolar panel: 200Wsolar panel: 300WCoefficient: 7hourssolar panel: 100Wsolar panel: 150Wsolar panel: 250W
Solar Charge Controller Technical DatePower35W80W100WMax20A20A20A
Please be noted: above solar configuration is only for reference, and we can set different solar configuration based on differents customers' demand.
