Pl90 Servo Planetary Gearbox
Ningbo Yinzhou Guda Imp. & Exp. Co., Ltd.- Application：Machinery, Industry
- Function：Speed Changing, Speed Reduction
- Layout：Coaxial
- Hardness：Hardened
- Installation：Vertical Type
- Step：Double-Step
Base Info
- Model NO.：PL-90
- Type：Planetary Gear
- Material：Stainless Steel
- Manipulate Way：Forced Manipulation
- Manufacturing Method：Cut Gear
- Toothed Portion Shape：Spur Gear
- Changes Way：Stepped
- Transport Package：Wooden Cases or Cartons
- Specification：PL-90
- Trademark：SHENGHUI
- Origin：China
- HS Code：8483409000
- Production Capacity：1000000
Description
TypePL-40 PL-60 PL-90 PL-120 PL-160 PL-200 Ratio Stages T2N
Rated output torque
(Nm) 10 28 120 220 480 1230 3 1 15 48 150 270 590 1780 4 15 48 150 270 590 1345 5 9 39 110 215 470 745 7 7 19 58 98 260 720 10 10 28 120 220 480 1230 9 2 15 48 150 270 590 1485 15 15 48 150 270 590 2035 20 15 48 150 270 590 1485 25 15 48 150 270 590 2035 30 15 48 150 270 590 1450 35 15 48 150 270 590 1485 40 15 48 150 270 590 1450 50 9 39 110 215 470 840 70 7 19 58 98 260 720 100 15 48 150 270 590 2590 64 3 15 48 150 270 590 2590 80 15 48 150 270 590 2590 100 15 48 150 270 590 2590 150 15 48 150 270 590 1855 200 15 48 150 270 590 2596 250 15 48 150 270 590 1855 350 15 48 150 270 590 1450 400 15 48 150 270 590 1070 500 9 39 110 215 470 1070 700 7 19 58 98 260 1070 1000
emergency stop torqueT2not=2T2N Rotational inertia
(kgm2) 0.031 0.0135 0.77 2.63 12.14 15.6 3 1 0.022 0.093 0.52 1.79 7.78 16.3 4 0.019 0.078 0.45 1.53 6.07 15.4 5 0.017 0.065 0.39 1.32 4.63 16.1 7 0.016 0.065 0.39 1.32 4.63 15.2 10 0.03 0.131 0.74 2.62 12.14 15.9 9 2 0.023 0.077 0.71 2.53 12.35 15 15 0.019 0.075 0.44 1.5 6.65 15.7 20 0.019 0.075 0.44 1.49 5.81 15.3 25 0.017 0.064 0.39 1.3 6.36 15.2 30 0.016 0.064 0.39 1.3 5.28 16.1 35 0.016 0.064 0.39 1.3 5.28 15.2 40 0.016 0.064 0.39 1.3 4.5 15.2 50 0.016 0.064 0.39 1.3 4.5 15.2 70 0.016 0.058 0.31 1.12 3.53 15.2 100 0.019 0.075 0.5 1.5 7.5 15.4 80 3 0.019 0.075 0.44 1.49 7.4 15.4 100 0.016 0.064 0.39 1.3 6.5 15.2 150 0.016 0.064 0.39 1.3 6.2 15.2 200 0.016 0.064 0.39 1.3 5.7 15.2 250 0.016 0.064 0.39 1.3 5.4 15.2 350 0.016 0.064 0.39 1.3 5.4 15.2 400 0.016 0.064 0.39 1.3 5.2 15.2 500 0.016 0.064 0.39 1.3 5.2 15.2 700 0.016 0.064 0.39 1.3 5.2 15.2 1000 backslash
(arcmin) reduced <5 <3 <3 <3 <5 <10 1 standard <10 <8 <8 <8 <10 <15 reduced <8 <5 <5 <5 <8 <15 2 standard <12 <10 <10 <10 <10 <18 reduced <10 <8 <8 <8 <10 <18 3 standard <15 <12 <12 <12 <15 <22 torsional rigidity
(Nm/arcmin) 0.7 1.8 4.4 9.2 26.7 66.7 noise dB(A) 55 58 60 65 70 75 Max.input speed 10000 8000 6000 6000 5000 3500 1-min Rated input speed 4500 4000 4000 3500 2000 1500 1-min Max.Radialforce(N) 185 265 400 1240 3700 6700 Stages Max.Axialforce(N) 150 200 420 1000 3500 3800 Full-load efficiency(%) 96 1 94 2 90 3 service life (H) 20000 Weight (Kg) 0.5 1 3 6.2 19 42 1 0.8 1.5 4.2 8 24 50 2 1.1 1.8 4.8 9.8 29 58 3
