Portable Soundproof Mobile LED Lighting Tower
Hebei Rongyuan Plastic Products Co., Ltd.- Warranty：3 Year
- Fuel Capacity：15L
- Optional Colour Temperature：2100k-5700k
- Lumen Output：4*25000
- Total Height Top：4.8m
- Rotation：360 Degrees
Base Info
- Model NO.：RPLT-1600B
- Duty Stabiliser Legs：4*Manual
- Tyre Size：25cm
- Tow Hitch：Ring, Ball Hitch
- Total Power of Lamp：4*400W
- Transport Package：Plywood Pallet , Plywood Case , Cartons
- Specification：ISO9001: 2000. CE
- Trademark：Robust Power
- Origin：China
- HS Code：94054090
- Production Capacity：250sets,Month
Description
MastMaximum extention of mast 4.8m Elevation Manual Raising/lowing mast Winch(Mechanical) Stages 4 Turning angle 358 degrees non-continuous Lamp Total power of lamps 4× 400W /4X1000W Type of lamp Metal halide lamp Light capacity 4× 25000 lumen Frequency 50Hz/60HZ Working temperature ≤ 85 Connection Protection index IP54 Characteristics of the generator Model RPD6500I(Made in China) Generator set Prime power 50Hz 4.2kW 60HZ 5.0KW Engine model RP186FA Diesel Engine speed 50Hz 3000rpm 60HZ 3600rpm Engine type 1 cylinder, 4-stroke, Air-cooled Engine Aspiration Natural Alternator Type 2-pole, brushless Fuel tank capacity 15L Prime fuel consumption at 100% load 1.85L/h Working hours 8 Control system Digital control panel Power Outlets 2 Trailer Stabilier Supports 4 × Manual Anti-wind capacity ≤ 6 Brakes Manual Packing Dimension & Weight Retracted Dimension 1300mm × 840mm × 2600mm Container load (20/40FT) 12/24(At least) Net weight 270kg
