• Model NO.：08125-08237
• Material：Bearing Steel
• Spherical：Non-Aligning Bearings
• Load Direction：Radial Bearing
• Separated：Separated
• Product Name：Timken 08125-08237 Tapered Roller Bearings
• Operating Temperature Ranger：-40 to 120 ºC
• Vibration：Zv1, Zv2, Zv3, or as Requested
• Transport Package：Single Box Packaging,OEM
• Specification：100*180*37mm
• Trademark：TFN,OEM,SEMRI
• Origin：China
• HS Code：8482200000
• Production Capacity：10000,Month
• Package size per unit product：30.00cm * 50.00cm * 26.00cm
• Gross weight per unit product：1.000kg

Basic Info.

Model NO. 08125-08237 Material Bearing Steel Spherical Non-Aligning Bearings Load Direction Radial Bearing Separated Separated Product Name Timken 08125-08237 Tapered Roller Bearings Operating Temperature Ranger -40 to 120 ºC Vibration Zv1, Zv2, Zv3, or as Requested Transport Package Single Box Packaging/OEM Specification 100*180*37mm Trademark TFN/OEM/SEMRI Origin China HS Code 8482200000 Production Capacity 10000/Month

Packaging & Delivery

Package size per unit product 30.00cm * 50.00cm * 26.00cm Gross weight per unit product 1.000kg

Product Description

TIMKEN 08125-08237 tapered roller bearings

TIMKEN 08125-08237 Bearing details

Series	08000
model	08125-08237
Cone Part Number	08125
Cup Part Number	08237
Design Units	Imperial
Cage Type	Stamped Steel
Bearing Weight	0.200 Kg 0.4 lb
Dimensions
d - Bore	31.750 mm 1.2500 in
D - Cup Outer Diameter	58.788 mm 2.3145 in
B - Cone Width	15.080 mm 0.5937 in
C - Cup Width	10.716 mm 0.4219 in
T - Bearing Width	14.684 mm 0.5781 in
Abutment and Fillet Dimensions
R - Cone Backface "To Clear" Radius	1.020 mm 0.04 in
r - Cup Backface "To Clear" Radius	1.02 mm 0.04 in
da - Cone Frontface Backing Diameter	36.07 mm 1.42 in
db - Cone Backface Backing Diameter	37.59 mm 1.48 in
Da - Cup Frontface Backing Diameter	55.88 mm 2.20 in
Db - Cup Backface Backing Diameter	52.07 mm 2.05 in
Ab - Cage-Cone Frontface Clearance	1.8 mm 0.07 in
Aa - Cage-Cone Backface Clearance	0.5 mm 0.02 in
a - Effective Center Location	-1.30 mm -0.05 in
Basic Load Ratings
C90 - Dynamic Radial Rating (90 million revolutions)	8220 N 1850 lbf
C1 - Dynamic Radial Rating (1 million revolutions)	31700 N 7130 lbf
C0 - Static Radial Rating	35000 N 7880 lbf
Ca90 - Dynamic Thrust Rating (90 million revolutions)	6670 N 1500 lbf
Factors
K - Factor	1.23
e - ISO Factor	0.47
Y - ISO Factor	1.27
G1 - Heat Generation Factor (Roller-Raceway)	10.7
G2 - Heat Generation Factor (Rib-Roller End)	10.6
Cg - Geometry Factor	0.0601

TIMKEN 08125-08237 bearings, TS (Tapered Single) Imperial, Tapered roller bearings.


FAQ

1.Q:Are you a factory or trading company?
 A:SEMRI Bearing is specialized in manufacturing and exporting bearings.
 SEMRI Bearing have own factory and warehouse.
2.Q:Can I get some samples and do you offer the sample free?
 A:Yes, sure, SEMRI Bearing are honored to offer you samples.Can you buy a ticket ?3.Q:What is the payment?
  A: 30% T/T In Advance, 70% T/T Against Copy Of B/L
 B: 100% L/C At Sight
4.Q:What is the MOQ for bearing?
   A: SEMRI Bearing MOQ is 1 pc.
5.Q:What kind of service you can offer?
 A:Technology support;Installation guidance;OEM
