• Model NO.：BA2B309609AD
• Spoke Type：Equal Diameter Spoke
• Certification：ISO
• Wheel Hub Brand：Tfn
• Rolling Body：Roller Bearings
• The Number of Rows：Double
• Outer Dimension：Small and Medium-Sized (60-115mm)
• Spherical：Non-Aligning Bearings
• Load Direction：Radial Bearing
• Separated：Unseparated
• Product Name：Stainless Steel 5302 Angular Contact Ball Bearing
• Width：42mm
• Bore Diameter：42mm
• Outside Diameter：80mm
• Seals / Shields：Rubber Sealed
• Contact Angle：40 Degree , 35 Degree
• Weight：0.794kg
• MOQ：1
• Cage Material：Phenolic , Brass
• Mounting Arrangement：Duplex-Back to Back
• Transport Package：as Customer′s Requirements
• Specification：42x80x42mm
• Trademark：TFN
• Origin：Shangdong China
• HS Code：8482103000
• Production Capacity：500000,Year

Product Name

SKF Wheel Bearing BA2B309609 AD Angular Contact Ball Bearing

Brand

TFN / OEM

Model Number

BA2B309609AD

Dimension

42x80x42mm

Ring Material

Gcr15/ Carbon Steel/ Stainless Steel/ Si3N4/ ZrO2

Precision

P0, P6, P5,P4,P3,P2 or as requested

Vibration

ZV1, ZV2, ZV3, or as requested

Contact angle

C ,AC ,A ,B

Type

 30series,32 series,33series,38 series,53 series,53series

Features

High speed

High load carrying capacity

Long service life

Low friction

Excellent light load performance

Low noise

Angular contact ball bearing

Angular contact  ball bearings can withstand both radial and axial loads. Can work at higher speeds. The larger the contact angle, the higher the axial load carrying capacity. The contact angle is the angle between the line connecting the contact point of the ball and the raceway in the radial plane and the vertical line of the bearing axis. High precision and high speed bearings typically take a 15 degree contact angle. Under the axial force, the contact angle will increase.

Quality standard

ISO9001:2000/ SGS

Quality Control Process

1.Assembly

2.Windage test

3.Cleaning

4.Rotary test

5.Greasing and gland

6.Noise inspection

7.Appearance inspection

8.Rust prevention

9.Product packaging

Application

Used in Machine tool spindle, high frequency motor, gas turbine, centrifugal separator, small car front wheel, differential pinion shaft, booster pump, drilling platform, food machinery, indexing head, repair welding machine, low noise cooling tower, Electromechanical equipment, painting equipment, machine slot plate, arc welder etc.

Boundary dimensions(mm)Basic load ratings(kN)Limiting speeds(rpm)Mass(Kg) dDBrs minr1s minCrCorGreaseOil(Approx.)5200103014.30.6 6.953.814,00019,0000.0495201123215.90.6 9.155.0513,00017,0000.0575202153515.90.6 106.0511,00015,0000.0645203174017.50.6 12.87.99,90013,0000.0965204204720.61 1912.18,80012,0000.1535205255220.61 20.614.37,3009,8000.1755206306223.81 28.620.46,3008,4000.28652073572271.1 3827.85,5007,4000.4365208408030.21.1 42.532.54,9006,6000.595209458530.21.1 48374,4005,9000.645210509030.21.1 51424,0005,3000.68952115510033.31.5 63533,6004,9000.98652126011036.51.5 71.558.53,4004,5001.2752136512038.11.5 83.572.53,1004,2001.5752147012539.71.5 90.579.52,9003,9001.852157513041.31.5 9080.52,7003,6001.952168014044.42 10695.52,5003,4002.3952178515049.22 1121062,4003,2003.0652189016052.42 1401292,2003,0003.7352199517055.62.1 1591482,1002,8004.86522010018060.32.1 1781672,0002,7005.945200-2RS103014.30.6 6.953.814,000 0.0495201-2RS123215.90.6 7.64.513,000 0.0575202-2RS153515.90.6 8.25.2511,000 0.0645203-2RS174017.50.6 10.87.19,900 0.0965204-2RS204720.61 15.810.18,800 0.1535205-2RS255220.61 18.213.27,300 0.1755206-2RS306223.81 26.119.76,300 0.2865207-2RS3572271.1 3324.55,500 0.4365208-2RS408030.21.1 40.5324,900 0.595200-ZZ103014.30.6 6.953.814,000 0.0495201-ZZ123215.90.6 7.64.513,000 0.0575202-ZZ153515.90.6 8.25.2511,000 0.0645203-ZZ174017.50.6 10.87.19,900 0.0965204-ZZ204720.61 15.810.18,800 0.1535205-ZZ255220.61 18.213.27,300 0.1755206-ZZ306223.81 26.119.76,300 0.2865207-ZZ3572271.1 3324.55,500 0.4365208-ZZ408030.21.1 40.5324,900 0.5953021542191 17.210.19,90013,0000.1325303174722.21 20.412.19,00012,0000.1815304205222.21.1 20.612.78,00011,0000.2175305256225.41.1 30.520.56,7008,9000.3625306307230.21.1 39.527.55,7007,6000.5535307358034.91.5 49.5355,0006,6000.7665308409036.51.5 60.5444,4005,9001.0153094510039.71.5 72.5544,0005,3001.3453105011044.42 85.564.53,6004,8001.8153115512049.22 106823,3004,4002.32531260130542.1 12295.53,0004,0003.0553136514058.72.1 1381092,8003,7003.9653147015063.52.1 1551252,6003,5004.7453157516068.32.1 1681412,4003,2005.655302-2RS1542191 14.28.859,900 0.1325303-2RS174722.21 17.410.49,000 0.1815304-2RS205222.21.1 19.112.48,000 0.2175305-2RS256225.41.1 26.517.96,700 0.3625306-2RS307230.21.1 3324.35,700 0.5535307-2RS358034.91.5 49.5355,000 0.7665308-2RS409036.51.5 55404,400 1.015302-ZZ1542191 14.28.859,900 0.1325303-ZZ174722.21 17.410.49,000 0.1815304-ZZ205222.21.1 19.112.48,000 0.2175305-ZZ256225.41.1 26.517.96,700 0.3625306-ZZ307230.21.1 3324.35,700 0.5535307-ZZ358034.91.5 49.5355,000 0.7665308-ZZ409036.51.5 55404,400 1.01

Certificate

 FAQ

Q:Why choose us?

A:1. We are professional,have factory in shandong for many years.

   2. We are experienced for 10 years.

   3. We can offer a various kind of bearing with high quality:Z1V1,Z2V2,Z3V3 and best price



Q:How is the quality of your products?

A:The same quality, we have lower price.The same price,we have better quality.



Q:Except Angular contact  ball bearing ,what other main bearing do you have?

A:Cylindrical roller bearing,Taper Roller Bearing,Thrust roller bearing,Deep groove ball bearing,Spherical roller bearing etc.



Q:May I get BA2B309609AD bearing free samples?

A:We will charge a little sample fee for our regular designs or customized ones, These charges will be refunded to you when your mass production order is confirmed.



Q:Can you make the products as our requirement?

A:We have more than 10years' OEM experience. We supply products fo more than 300 automobile parts factories.
