Cylinder Block Surface Grinding-Milling Machine 3m9740cx130
Guangdong Seabond Import and Export Co., Ltd- After-sales Service：12 Hours When Got Informaiton
- Warranty：12 Month
- Transport Package：Wooden Case
- Specification：3100x1150x2200mm
- Trademark：sjmc
- Origin：China
Base Info
- Model NO.：3M9740CX130
- Production Capacity：50 Unit , Per Year
Description
Basic Info.
Model NO. 3M9740CX130 Production Capacity 50 Unit / Per YearProduct Description
3M9740C/130 CYLINDER BLOCK GRINDING-MILLING MACHINE
Cylinder block grinding-milling machine suitable for grinding every kind of motor's cylinder body and cover plane.Structure characteristic:
1. Spindle use high precision bearing with high machining precision.
2. machine run smoothly and with small resistance.
3. working table movement use frequency conversion stepless variable speed, suitable for machine different material parts.,
| CODE | ITEM | 3M9740C× 130 | 3M9740C× 150 |
| 1 | Dimensions of working table(mm) | 1300×500 | 1500×500 |
| 2 | Max. length of processing(mm) | 1300 | 1500 |
| 3 | Max. width of processing(mm) | 350 | 350 |
| 4 | Max. height of processing(mm) | 800 | 800 |
| 5 | Grinding head vertical travel(mm) | 800 | 800 |
| 6 | Moving speed of working table(mm/min) | 30~900 | 30~900 |
| 7 | Grinding segment Plate dia.(mm) | 360 | 360 |
| 8 | Main motor power(kw) | 1.5/2.4 | 1.5/2.4 |
| 9 | Overall dimension(LxWxH)(mm) | 2700×1000×1960 | 2950×1000×1960 |
