Portable Waterproof Diesel Generator Lighting Tower
Hebei Rongyuan Plastic Products Co., Ltd.- Warranty：3 Year
- Fuel Capacity：100L
- Optional Colour Temperature：2100k-5700k
- Lumen Output：4*110000
- Total Height Top：9m
- Duty Stabiliser Legs：4*Manual
Base Info
- Model NO.：RPLT-6000
- Tyre Size：13 Inch
- Tow Hitch：Ring, Ball Hitch
- Total Power of Lamp：4*1000W
- Type of Lamp：Metal Halide Lamp
- Transport Package：Plywood Pallet,Plwood Case,Cartons
- Specification：ISO9001: 2000, CE
- Trademark：Robust Power
- Origin：China
- HS Code：9405409000
- Production Capacity：100 Set,Month
Description
Model RPLT6000Technical Specifications Mast Maximum extention of mast 9m Elevation Mechanical Raising/lowing mast Winch(Mechanical) Stages 3 Turning angle 358 degrees non-continuous Lamp Total power of lamps 4×1000W Type of lamp Metal halide lamp Light capacity 4×110,000 lumen Voltage 230 or 240 Frequency 50Hz/60Hz Lifetime of lamp 5000hours Working temperature ≤85Degrees Celsius Connection Protection index IP54 Light Coverage 5 to 7 acres Characteristics of the generator Model RD-10 Generator set Prime power 50Hz 6.7kW / 60Hz 8.4kW Engine model Japan KUBOTA D1105-BG / UK PERKINS 403D-11G Engine speed 50Hz 1500rpm / 50Hz 1800rpm Engine type 3 cylinder,in line,water-cooled Engine Aspiration Natural Alternator STAMFORD PI 044F Alternator Type 4-pole, brushless Fuel tank capacity 70 L Prime fuel consumption at 100% load 2.0L/h Working hours 25 Control system GU602A Digital controller Power Outlets 2 Trailer Tow hitch Ring or ball hitch Stabilier Supports 5 × Manual Tire Size 52 cm Anti-wind capacity ≤10 Brakes Manual Packing Dimension & Weight Retracted Dimension 4400mm × 1350mm × 1930mm(Around) Mast Packing 3800mm ×350mm ×350mm (Around) Generator set packing 1550mm ×1150mm ×1610mm (Around) 1000W lamps packing 4 pcs 520mm ×520mm ×370mm (Around) Container load (40HQ) 6 Net weight 870kg
