UL Ce SMD 5060&SMD2835 RGBW LED Flexible Strip Light

Foshan Nanhai Xinqiguang Metal Cap Co., Ltd.
  • Certification：UL, RoHS, CE
  • Power：Max23W
  • Emitting Color：RGBW
  • Voltage：24VDC
  • IP Rating：IP44
  • LED Chip Brand：Premium Epistar Chip

Base Info

  • Model NO.：OL-5628FP-9624-RGBW
  • LEDs/M：RGB 48PCS + White 48PCS
  • Lumens：1200-1410lm,M
  • Color Rendering Index：CRI>80
  • PCB Width：12mm
  • Back Tape：3m 200MP Back Tape
  • Connection：DC Connector , 20AWG 2-Pin Bare Wire
  • MOQ：5m,Roll
  • Warranty：3 Years
  • Transport Package：50 Rolls,Carton
  • Specification：smd5050&smd2835
  • Trademark：Iris
  • Origin：China
  • HS Code：9405409000
  • Production Capacity：1000m,Day

Description

Item NumberColor TemperatureDetailsOL-5628FP-9624-RGBUWWRGB + ultra-warm white 2700KPremium Grade Epistar SMD 5060 and SMD 2835 Flexible RGBW Strips, 96LEDs/M (48 RGB LEDs and 48 White LEDs), 24VDC only, Max. 23W/M, Max.1400LM/M at Mix, 120 ° beam angle, CRI>90 for White color, IP43/65/66/67/68, 12mm wide White flexible PCB, TESA 4965 back tape, 1x20cm 20AWG 5-pin bare wire, UWW/WW/NW/CW, 5M/Roll.OL-5628FP-9624-RGBWWRGB + warm white 3000KOL-5628FP-9624-RGBWWRGB + warm white 3500KOL-5628FP-9624-RGBNWRGB + natrural white 4000KOL-5628FP-9624-RGBCWRGB + cold white 5800K
