Jiuhong Disposable Endoscopic Rotatable Hemostasis Clip

Anhui Baishijia Packing Co., Ltd.
  • Type：Surgical Supplies Materials
  • Material：Stainless Steel
  • Ethylene Oxide Sterilization：Ethylene Oxide Sterilization
  • Quality Guarantee Period：Two Years
  • Group：Adult
  • Logo Printing：Customized

Base Info

  • Model NO.：JHY-CD
  • Max. Open Width of Clip H (mm)：9.0, 11.0, 13.0
  • Tolerance (mm)：1.5
  • Diameter D (mm)：2.5
  • Working Length L(mm)：1100-2600
  • Transport Package：1PC,Bag
  • Specification：FDA, CE, ISO
  • Trademark：JIUHONG, OEM, GLOBAL
  • Origin：Changzhou, Jiangsu
  • HS Code：9018909010
  • Production Capacity：500000PCS

Description

ComponentMaterialStandardClip componentsX7CrNi17-7EN 10088-1-2005SleeveSUS316FEN 10088-1-2005Metal capX10CrNi18-9EN 10088-1-2005Spring sheathX5CrNi18-10EN 10088-1-2005Pulling wire componentsX5CrNi18-10EN10088-1-2005Coating LayerPEISO 1872-1-1993
 Protective TubeX5CrNi18-10EN 10088-1-2005SliderABS+TPEISO2580-1-2002
ASTM D5927-2009Core rodABS+TPEISO2580-1-2002
ASTM D5927-2009

4. Specification:
 ModelO.D.
(mm)Work Length(mm)Clip Opening Width(mm)Endoscope Channel(mm)JHY-CD11-25-1602.5160011≥2.8JHY-CD11-25-1802.5180011≥2.8JHY-CD11-25-2302.5230011≥2.8JHY-CD13-25-1602.5160013≥2.8JHY-CD13-25-1802.5180013≥2.8JHY-CD13-25-2302.5230013≥2.8
