• Model NO.：16009-2Z
• Feature：Long Life High Speed
• Vibration：Z1V1~Z4V4
• Transport Package：Single Box, Industry Packing, Pallet an So on
• Specification：10mm~200mm
• Trademark：NSK, CVP or OEM
• Origin：Shangdong
• HS Code：8482102000
• Production Capacity：100000,Month

Bearing Model16009-2ZTypeDeep groove ball bearingBore Size (mm)45Outside Diameter (mm)75Width (mm)10Mass (kg)0.171MaterialChrome Steel, Carbon steel, Stainless steelCage MaterialNylonNumber of RowSingle RowPrecision RatingP5. P6Basic Dynamic Load Rating (Cr)23.4 kNBasic Static Load Rating (Cor)11.6 kNLimiting Speed7500 r/min

Packing & Delivery:

Single box--Paper carton--Wooden case
3-5 days upon your confirmation of the order

Specifications:

1. High precision bearings
2. ISO standard
3. Material:Gcr15 High- carbon chrome steel


Our Service



1. We are a manufacturer of producing bearing for more than ten years of experience in product.

2. The Most advanced machinery and a strict quality control team.

3. On-time delivery service.

4. Accept non-standard production according to customers' requirement.

5. High level of performance, quality, of all equipment and service.

6. Promptness in technical support pre- and after sales.

7. Do OEM for our customers.



Bearing No.Inner diameterOuter diameterWidthRated loadSteel ball parametersLimit speed(RPM)WeightDynamicStaticNo.SizeGreaseOildDBCrCormmr/minr/minKG16001122875.12.484.7632600030000.01916002153285.62.894.76322000260000.02516003173586.83.35104.76320000240000.03216004204287.94.5105.55618000210000.05116005254788.355.1125.55615000180000.059160063055911.27.4126.3513000150000.091160073562911.78.2146.3512000140000.107160084068912.69.65156.3510000120000.1251600945751012.910.5166.359200110000.1711601050801013.211.3167.144840098000.181601155901118.615.3167.938770090000.258160126095112017.5187.144700083000.28316013651001120.518.7207.144650077000.30716014701101324.422.6159.525610071000.4411601575115132524169.525570067000.46416016801251425.425.11511.112530062000.59716017851301425.926.21611.112500059000.62616018901401633.533.51512.7470056000.8481605226040044235310  1100150022.5
