Front Service P8mm SMD3535 Outdoor LED Full Color Display Screen for Shop
Guangzhou Zhonghao Packaging Products Co., Ltd.- Tube Chip Color：Full Color
- IP Rating：IP65
- Pixel Pitch：8mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display
- Average Power Consumption：350W , m²
Base Info
- Model NO.：P8
- Pixel Density：15625pixel,Sqm
- Scanning Mode：Static Scan
- Display Type：LED Video Display
- Application：Advertising
- Certification：CE, CCC, ETL
- Size：1024X2048mm
- Water Proof：IP65
- Pacakge：Wooden Case
- Maintainence：Front Service
- Transport Package：Wooden Case
- Specification：CE, ROHS, ISO9001
- Trademark：BST
- Origin：Shenzhen, China
- HS Code：8528591090
- Production Capacity：5000sqm,Months
Description
Model No.
BST-OFS-8
Pixel Pitch
8mm
Module Size
256mm*256mm
Module Resolution(pixels)
32*32
Pael Size
1024mm×768mm
Panel Resolution(pixels)
128×96
Pixel Configuration(RGB)
SMD3535
Pixel Density(pixels/m2)
15625
Brightness(cdm2)
>5500
Best Viewing Distance(m)
8-100
Max.Power Consumption(W/m2)
>1000
Waterproof Level
IP65
Wavelength
R 620-625 G 520-525 B 470-475
LED SPEC
3535
Viewing Angle
140°(H)/140°(V)
Operating Tempreture
-20~50°C
Video Frame Rate(Hz)
≥60HZ
Display Refresh Rate(Hz)
≥1500HZ
Grey Level(colors)
16.7million
MTBF
≥50000 hours
Lifespan
≥100000Hours
Working Voltage
220V±10% OR 110V±10%
Drive Mode
Constant 1/4
Graphics Card
DVI Graphics card
Video Signal
RF, S-Video, RGB, RGBHV, YUV, YC, etc.
Control System
LINSN
Software
LED studio 10.0
Installation
Wall mount, and stand structure
