Cheapest Factory Manufacturer of Worm Reduction Gearbox for Converyor

QINGDAO GUARDX IMP & EXP CO., LTD.
  • Application：Industry
  • Hardness：Hardened
  • Type：Worm and Wormwheel
  • Gearing Arrangement：Worm
  • Output Torque：182n.M~~901n.M
  • Rated Power：0.55kw~~7.5kw

Base Info

  • Model NO.：NMRV110
  • Input Speed：1400rpm
  • Output Speed：14~~186rpm
  • Speed Ratio：7.5,10,15,20,25,30,40,50,60,80,100
  • Worm Gear Material：Chromium Alloy 40cr
  • Worm Wheel Material：Bronze 10#-1
  • Color：Blue,Silver,Coustomzied
  • Certificate：ISO9001:2008tccc, CE
  • Material：Cast Iron
  • Manipulate Way：Semi-Automatic Manipulation
  • Manufacturing Method：Cast Gear
  • Toothed Portion Shape：Spur Gear
  • Changes Way：Stepless
  • Transport Package：1 PC , Carton, Several Cartons , Wooden Pallet
  • Trademark：chenxin
  • Origin：Zhejiang, China (Mainland)
  • Production Capacity：20000set, Month

Description

0.55kw

1400rpm

NMRV1108018rpm201.0N.MNMRV11010014rpm236.0N.M

0.75kw

1400rpm

NMRV1105028rpm194.0N.MNMRV1106024rpm227.0N.MNMRV1108018rpm274.0N.MNMRV11010014rpm322.0N.M

1.1kw

1400rpm

NMRV1104035rpm237.0N.MNMRV1105028rpm278.0N.MNMRV1106024rpm324.0N.MNMRV1108018rpm402.0N.MNMRV11010014rpm473.0N.M

1.5kw

1400rpm

NMRV1102556rpm218.0N.MNMRV1103047rpm246.0N.MNMRV1104035rpm315.0N.MNMRV1105028rpm379.0N.MNMRV1106024rpm442.0N.MNMRV1108018rpm548.0N.MNMRV11010014rpm655.0N.M

2.2kw

1400rpm

NMRV1101594rpm196.0N.MNMRV1102070rpm255.0N.MNMRV1102556rpm311.0N.MNMRV1103047rpm356.0N.MNMRV1104035rpm462.0N.MNMRV1105028rpm555.0N.MNMRV1106024rpm648.0N.M

3.0kw

1400rpm

NMRV11010140rpm182.0N.MNMRV1101594rpm264.0N.MNMRV1102070rpm348.0N.MNMRV1102556rpm425.0N.MNMRV1103047rpm485.0N.MNMRV1104035rpm630.0N.MNMRV1105028rpm757.0N.M

4.0kw

1400rpm

NMRV1107.5186rpm184.0N.MNMRV11010140rpm240.0N.MNMRV1101594rpm352.0N.MNMRV1102070rpm454.0N.MNMRV1102556rpm566.0N.MNMRV1103047rpm647.0N.MNMRV1104035rpm863.0N.M

5.5kw

1400rpm

NMRV1107.5186rpm250.0N.MNMRV11010140rpm330.0N.MNMRV1101594rpm484.0N.MNMRV1102070rpm638.0N.MNMRV1102556rpm798.0N.MNMRV1103047rpm901.0N.M

7.5kw

1400rpm

NMRV1107.5186rpm341.0N.MNMRV11010140rpm450.0N.MNMRV1101594rpm660.0N.MNMRV1102070rpm880.0N.M

Technical data:



ModelRV025 030 040 050 063 075 090 110 130 150Single unit versions

NMRV - fitted for motor flanged coupling,

NRV - with input shaft,

NMRV-E motor flanged coupling with worm extension shaft,

NRV-E with double extension worm shaft,

 Power0.06----15KW  Single unit reduction ratio 1:5 7.5 10 15 20 25 30 40 50 60 80 100 Output torque 2.6---1195N.M Worm shaft 20CrMnTi with carburizing and quenching.The hardness of surface is 56-62HRC with carbonized layer 0.5-0.8mm Worm wheel worm mandrel is HT250,and worm ring gear,ZQSn10-1
