Battery and Diesel Generator 4X300W LED Floodlight Hybrid Light Tower
Hebei Rongyuan Plastic Products Co., Ltd.- Battary：4X12X150ah
- Battery Full Charged by Genset：Need 10 Hours
- Battery Continuous Discharge Capacity：5 Hours
- Engine：Kubota Z482-Bg
- Fuel Capacity：0.8L,Hr(80 Litres,Tank)
- Voltage：48V DC
Base Info
- Model NO.：RPLT3700
- Power Generation：3kw Continuous (DC)
- Engine Speed：2200rpm
- Light Power：4*300W SAA Certified Robust Power LED Lamps
- Lumen Output：4*42, 000lm
- Transport Package：Plywood Tray,Plywood Cases,Cartons
- Specification：1540*1400*2000mm
- Trademark：Robuster Lighting
- Origin：China
- HS Code：94054090
- Production Capacity：250sets,Month
Description
Basic Info.
Model NO. RPLT3700 Power Generation 3kw Continuous (DC) Engine Speed 2200rpm Light Power 4*300W SAA Certified Robust Power LED Lamps Lumen Output 4*42, 000lm Transport Package Plywood Tray/Plywood Cases/Cartons Specification 1540*1400*2000mm Trademark Robuster Lighting Origin China HS Code 94054090 Production Capacity 250sets/MonthProduct Description
Battery And Diesel Generator 4x300W LED Floodlight Hybrid Light TowerKey Features Include:
8m hydraulical operated telescopic mast
340 mast rotation
Available in 4 x 300W SAA Certified Robust Power LED lamp
Galvanized mast and powder coated canopy
Electronic controlled hydraulic system with sustaining valves and hydraulic locks
Fault protection
Heavy-duty, weather-protective enclosure
Fully bunded
Technical Data:
| Light | |
| Housing Material | Aluminium die cast |
| Type of lights | LED Lamp |
| Power of lights | 4*300W SAA certified Robust Power LED lamps |
| Lumen Output | 4*42,000lm ( total ) |
| Voltage | DC 48V |
| Longevity | 3 years |
| Waterproof grade | IP65 |
| Color temperature | 2100K-5700K |
| Mast | |
| Material of mast | Galvanized iron |
| Mast lifting type | Hydraulic mast |
| Mast section | 4-section telescopic |
| Mast rotation system | 340° manual operation |
| Max. height of mast | 8meters |
| Engine | |
| Engine model | Kubota Z482 2 cylinder |
| Start system | Electric (Battery start) |
| Alternator | Chinese brand copy Stamford |
| Engine speed | 2200rmp |
| Rated power | 3.5kW continuous (DC) |
| Insulation | H |
| Fuel tank capacity | 80L |
| Fuel consumption | 0.8L/hr |
| Maximum Working Hours | 90H |
| Controller system | Digital control panel HGM1790N |
| Waterproof grade | IP54 |
| Engine shutdown protection | Low oil pressure, over speed, over current, high-temperature detection, low fuel level |
| Battery system | |
| Battery materials | Gel battery |
| Battery capacity | 4x12Vx150AH |
| The battery voltage | 48V |
| Charging way | The power converter |
| Battery full charged by genset | Need 10 hours |
| Battery continuous discharge capacity | 5 hours |
| Packing | |
| Net weight | 1800/1700 kg |
| Dimension | 1540X1400X2000 MM |
Robust Power Models:
| No. | Model | Mast | Power of Lamps | Engine Model |
| 1 | RPLT1600 | 4.8M Manual | 4*400W Metal Halide Lamp | RP186FA |
| 2 | RPLT1600 | 4.8M Manual | 4*160W LED | RP186FA |
| 3 | RPLT1600 | 4.8M Manual | 2*1000W Metal Halide Lamp | RP186FA |
| 4 | RPLT6000 | 9M Manual | 4*1000W Metal Halide Lamp | Kubota D1105 (Japan) |
| 5 | RPLT6000 | 9M Manual | 4*240W LED | Kubota D905 (Japan) |
| 6 | RPLT6800 | 8.6M Hydraulic | 4*1000W Metal Halide Lamp | Kubota D1105 (Japan) |
| 7 | RPLT6800 | 8.6M Hydraulic | 4*1500W Metal Halide Lamp | Kubota D1105 (Japan) |
| 8 | RPLT6800 | 8.6M Hydraulic | 4*480W LED | Kubota D905 (Japan) |
| 9 | RPLT3800 | 7M Hydraulic | 4*480W LED | Kubota Z482 (Japan) |
| 10 | RPLT6900 | 8.5M Hydraulic | 4*480W LED | Kubota D1105 (Japan) |
| 11 | RPLT7200 | 10M Hydraulic | 6*480W LED | Kubota D1105 (Japan) |
| 12 | RPLT7200 | 10M Hydraulic | 4*720W LED | Kubota D1105 (Japan) |
| 13 | RPLT7600 | 9M Hydraulic | 6*480W LED | Kubota D1105 (Japan) |
| 14 | RPLT7600 | 9M Hydraulic | 4*720W LED | Kubota D1105 (Japan) |
