Zys Machine Parts One Way Bearing Clutch Bearing Csk8 8X22X9 mm for Textile Machinery with Csk, Hf, Asnu Series Bearing
Hengtailong Plastic Net Co. Ltd- Rolling Body：Roller Bearings
- The Number of Rows：Single
- Outer Dimension：Small (28-55mm)
- Material：Bearing Steel
- Spherical：Non-Aligning Bearings
- Load Direction：Radial Bearing
Base Info
- Model NO.：Csk8
- Separated：Separated
- Accuracy Class：P2,P5,P6,P4,P0
- Sealing Type：Open Type and Sealed Type
- Clearance：C0, C2, C3
- Feature：Low Noise High Speed Long Life Durable
- Certification：ISO9001:2008, IATF 16949
- Application：Heavy Duty,Load Trucks Clutch, Washing Machine
- Delivery Time：Within One Week
- Bearing Use：Speed Conversion, Reversal Preventing, Intermitten
- Transport Package：Single Box or as Your Requirements
- Specification：customized
- Trademark：ZYS or OEM
- Origin：Luoyang, Henan, China
- HS Code：848360009
- Production Capacity：50000PCS Per Month
Description
Overview
Product Description
Features of ZYS one way clutch bearings:
Small size, transmitting high torque, smooth combining, high slip combining, working without noise, etc.
Product Parameters
Fitted inner raceway diameter: φ 10mm~φ 120mm
Minimum mounting width: 15mm~30mm
Rated torque: 60N. M~4000N. MType Size Bearing series Bearing loads Weight Drag torque dynamic static d TKN1) nmax D L b t C C0 TR [mm] [Nm] [min-1] [mm] [mm] [mm] [mm] [kN] [kN] [kg] [Ncm] CSK..P 12 6201 9.3 10000 32 10 6.1 2.77 0.04 0.7 15 6202 17 8400 35 11 7.4 3.42 0.06 0.9 17 6203 30 7350 40 12 7.9 3.8 0.07 1.1 20 6204 50 6000 47 14 9.4 4.46 0.11 1.3 25 6205 85 5200 52 15 10.7 5.46 0.14 2 30 6206 138 4200 62 16 11.7 6.45 0.21 4.4 35 6207 175 3600 72 17 12.6 7.28 0.3 5.8 40 - 325 3000 80 22 15.54 12.25 0.5 7 CSK..PP 15 6202 17 8400 35 11 2 0.6 7.4 3.42 0.06 0.9 17 6203 30 7350 40 12 2 1 7.9 3.8 0.07 1.1 20 6204 50 6000 47 14 3 1.5 9.4 4.46 0.11 1.3 25 6205 85 5200 52 15 6 2 10.7 5.46 0.14 2 30 6206 138 4200 62 16 6 2 11.7 6.45 0.21 4.4 35 6207 175 3600 72 17 8 2.5 12.6 7.28 0.3 5.8 40 - 325 3000 80 22 10 3 15.54 12.25 0.5 7 CSK..P-2RS 12 - 9.3 10000 32 14 6.1 2.77 0.05 3 15 - 17 8400 35 16 7.4 3.42 0.07 4 17 - 30 7350 40 17 7.9 3.8 0.09 5.6 20 - 50 6000 47 19 9.4 4.46 0.145 6 25 - 85 5200 52 20 10.7 5.46 0.175 6 30 - 138 4200 62 21 11.7 6.45 0.27 7.5 35 - 175 3600 72 22 12.6 7.28 0.4 8.2 40 - 325 3000 80 27 15.54 12.25 0.6 10
ZYS One Way Bearings are divided into open type and sealed type. The keyway can be machined on the inner ring and outer ring.
ZYS freewheel clutch is mainly used in such applications as speed conversion, reversal preventing, intermittent movement and etc. Working principle is to use friction generated by wedge, spring and such compression elements to transmit torque.Features of ZYS one way clutch bearings:
Small size, transmitting high torque, smooth combining, high slip combining, working without noise, etc.
Product Parameters
Technical parameters of ZYS one way clutch bearings:
Fitted outer raceway diameter: φ 30mm~φ 150mmFitted inner raceway diameter: φ 10mm~φ 120mm
Minimum mounting width: 15mm~30mm
Rated torque: 60N. M~4000N. M
