Insulation Bearing for High Speed Motor and Wind Turbine

Hengtailong Plastic Net Co. Ltd
  • Rolling Body：Roller Bearings
  • The Number of Rows：Single
  • Outer Dimension：Medium and Large(120-190mm)
  • Material：Bearing Steel
  • Spherical：Aligning Bearings
  • Load Direction：Axial Bearing

Base Info

  • Model NO.：NU1030M1-J20A-C4
  • Separated：Unseparated
  • Transport Package：Plain White Box
  • Trademark：ZYS
  • Origin：China
  • Production Capacity：50000PC,Month

Description

SuffixDescription SpecificationJ20BOuter ring coatedWithstanding voltage<500V, Coating depth<100μm, Size range 70-1400mmJ20AOuter ring coatedWithstanding voltage<1000V, Coating depth>200μm, Size range 70-1400mmJ20AAOuter ring coatedWithstanding voltage<1000V, Coating depth≈200μm, Size range 70-500mmJ20CInner ring coatedWithstanding voltage<1000V, Coating depth≈200μm, Size range 70-340mmV3031AOuter ring coated V3031BInner ring coated V3031CHybrid ceramic bearing VL0241Outer ring coated VL0246Outer ring coated VL2071Inner ring coated VL2076Inner ring coated SQ77Outer ring coated SQ77EInner ring coated
Specification of NU1030M1-J20A-C4Type             Specification    Load CapicityRadial ClearanceDepth of coating Withstand Voltage  Resistance IDODWidthCrCorNU1030M1-J20A-C4150mm225mm35mm261kN366kN0.165-0.215mm200-300μm         1000V     500MΩ
