Outdoor Full Colour Rental LED Display Screen P8 for Stage
Emoer Industry Limited- Tube Chip Color：Full Color
- IP Rating：IP65
- Pixel Pitch：8mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display, Image & Text Display, Text Display, Market Display
- Average Power Consumption：300W , m²
Base Info
- Model NO.：p8
- Pixel Density：15625 Dots,Sqm
- Scanning Mode：1,8 Scan
- Display Type：LED Video Display
- Application：Advertising
- Certification：CE, RoHS, UL, CCC, ETL
- Module Size：320X160mm
- Deliver Time：15-20 Days
- Density：15625
- Pixel：8mm
- Warranty Period：3 Years
- Package Mode：SMD 3535
- Average Power：300W,Sqm
- Max Average Power：800 W, Sqm
- Scan Model：1,5 Scan
- Waterproof Class：IP65
- Transport Package：Wooden Case or Air Case
- Specification：960x960x175mm
- Trademark：FWS
- Origin：Shenzhen China
- HS Code：8528591090
- Production Capacity：30000 Sqm , Months
Description
LED LampType HongshengSMD3535 Brand Epistar Arrangement 1R1G1B Chip parameters Red (620-625nm) IV:(800-960mcd) Chip parameters Green (520-525nm) IV:(1350-1650mcd) Chip parameters Blue (470-475nm) IV:(330-400mcd) LED Module Pixel Pitch 8mm Module Size(W*H) 320×160mm Module Resolution 40×20=800(Dots) Module Weight 0.5kg LED Cabinet Pixel Density 15625 Dots/sqm Cabinet Dimension(W*H*D) 960×960×175mm Cabinet Resolution 120×120=14400(Dots) Module Quanty /Cabinet 3×6=18(Pcs) Cabinets Material Aluminum-magnesium alloy Cabinet Cabinet Weight 25kg Brightness >7500cd/sqm Viewing Angle 120(Horizontal), 120(Vertical) Nearest Viewing Distance 11m Power Consumption (Max) 1000 w/sqm Power Consumption (Average) 300 w/sqm Refresh Rate >800Hz Drive Mode/Driver Position Constant driving 1/5 Scan, Combined diver board Display Function Text, Graphics, Video Frame Frequency no less than 60 frame/sec Input Voltage AC110-220V±10%, 50/60Hz Output Voltage DC-5V, 40A/60A/80A Color Grayscale 16bit Gray Scale per Color 65536 level Color Processing R(1024)×G(1024)×B(1024) Brightness Adjustment 256 color levels, can be adjusted manually and automatically optional MTBF( mean time between failures) 5000 hours Life-span 100, 000 hours Protection Level(front/back) IP66/IP54 Malfunction Dot Rate less than 0.0001 Working Temperature -30oC~50oC Humidity 15%~85% Control System Control Method Synchronization/Asynchronization Control System Sending Card, Receiving Card, Receiving HUB Software LED Studio(FWS-linsn) Language Chinese, Traditional Chinese, English, French, Japanese, Russian, Thai, Spanish, Polish, Italian, Portuguese, Turkish, Dutch, Greek, Bulgarian, Romanian, Arabic,Korean,German Control Card Input DVI, USB, RJ45, HDMI(Sold separately) Input Signal AVI/MPG/MPEG/TXT.etc PC Operating System Microsoft Windows 10 ,Windows 7 and XP Communication Type Net cable, 3G, WIFI(Sold separately) Certificate CE, ROHS, FCC, ISO9001, TUV
High Gray Scale-Better Picture
The 960mm LED Screen Rental is manufactured by using best quality material, purchased from most reputed vendors. The final products feature supreme quality and offers best outputs. High refresh rate and 16bit gray scale ensures the picture quality remains seamless.
Get Every Detail in picture
We spend some time with every detail of the 960mm LED Screen Rental, so that you can enjoy every detail of your marketing pictures. The pixel-perfect pictures are a treat to watch. It means, you will not miss any detail in the picture, video or text displayed on the screen
Seamless Splice
The 960mm LED Screen Rental can be installed within minutes, without any special tools. You may configure the 960mm LED Screen Rental as per your requirements and choice. Adjust the brightness, gray scale and picture quality as per your choice. Advanced adjustment options allow you to set up the display as per the environment conditions and area of installation.
High Gray Scale-Better Picture
The 960mm LED Screen Rental is manufactured by using best quality material, purchased from most reputed vendors. The final products feature supreme quality and offers best outputs. High refresh rate and 16bit gray scale ensures the picture quality remains seamless.
