Non-Stretch Flange Universal Joint Shaft Coupling/Cardan Shaft
Jiaxing City Qunbang Hardware Co., Ltd.- Standard Or Nonstandard：Standard
- Shaft Hole：as Your Requirement
- Torque：as Your Requirement
- Bore Diameter：as Your Requirement
- Speed：as Your Requirement
- Structure：Flexible
Base Info
- Model NO.：SWC-WF
- Material：35CrMo
- Type：Universal Coupling
- Connection：Flange
- Transport Package：Wooden Box
- Specification：as your requirement
- Trademark：Huading
- Origin：China
- HS Code：8483600090
- Production Capacity：5000pieces,Year
Description
Overview
Model
D
Tn/
kN·m
Tf/
kN·m
β/
(°)≤
Lmin D1
(js11) D2
(H7) D3 Lm n-d k t b
(h9) g
I/kg·m2 m/kg Lmin 100 Lmin 100 SWC180WF 180 12.5 6.3 25 560 155 105 114 110 8-17 17 5 - - 0.248 0.007 58 2.8 SWC225WF 225 40 20 15 610 196 135 152 120 8-17 20 5 32 9 0.636 0.0234 93 4.9 SWC250WF 250 63 31.5 15 715 218 150 168 140 8-19 25 6 40 12.5 1.352 0.0277 143 5.3 SWC285WF 285 90 45 15 810 245 170 194 160 8-21 27 7 40 15 2.664 0.051 220 6.3 SWC315WF 315 125 63 15 915 280 185 219 180 10-23 32 8 40 15 4.469 0.0795 300 8 SWC350WF 350 180 90 15 980 310 210 267 194 10-23 35 8 50 16 7.388 0.2219 412 15 SWC390WF 390 250 125 15 1100 345 235 267 215 10-25 40 8 70 18 13.184 0.2219 588 15 SWC440WF 440 355 180 15 1290 390 255 325 260 16-28 42 10 80 20 23.25 0.4744 880 21.7 SWC490WF 490 500 250 15 1360 435 275 325 270 16-31 47 12 90 22.5 40.75 0.4744 1173 21.7 SWC550WF 550 710 355 15 1510 492 320 426 305 16-31 50 12 100 22.5 68.48 1.357 1663 34 SWC620WF 620 1000 500 15 1690 555 380 426 340 10-38 55 12 100 25 127.53 1.357 2332 34
