• Model NO.：UHD-P1.5S
• System Operating Platform：WIN XP
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP31
• Certification：CE, RoHS, UL, CCC, ETL
• Cabinet Material：Die-Cast Aluminum
• Cabinet Weight：7.6kg
• Resolution：3840Hz
• Brightness：1000nits
• Life Span：100000 Hours
• Voltage：AC110-240V
• Contrast Rate：3000:1
• Control System：Novastar
• Transport Package：Flight Case or Wood Case
• Specification：600*337.5mm
• Trademark：LEDventure
• Origin：China
• HS Code：852859109
• Production Capacity：4000m2,Month

Detailed Photos

Product Parameters

Item

UHD Series Indoor Wall Mounted LED Video Wall Display Screen

Model Number

UHD-P1.5S

Pixel Pitch

1.5mm

Pixel Density

409600 pixels/M2

Pixel Configuration

SMD 3 IN 1

LED Type

NS, SMD

Module Size

150x337.5mm

Module Resolution

96*216p

Min.Viewing Distance

1.5m

Brightness

800-1000nits

Viewing Angle

≤140°

Average Power Consumption

300W

Scan Mode

1/32 Scan

Protection Level

IP31

Cabinet Size

600x337.5mm

Color Temperature

The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements

Input Voltage

AC110-240V, 50Hz/60Hz

Refresh Rate

3840hz

Color

65535 Levels

Horizontal/Vertical Viewing Angle

<140°

Gray Scale

16 bits

Effective Communication Distance(without relay)

Lifespan

≥100,000 hours

Environment Temperature

Storage: -40°C~+85°C  , Operation: -20 °C~+45°C

Blind Spot Rate

<0.0001(led display industry standard is less than 0.0003)

Control Mode

Video frequency synchronization

Shenzhen LEDventure Company is a professional solution service provider of LED display products, focusing on R&D, production, sales and service of LED stadium screen, LED rental screen, small pitch LED display, LED color screen, LED floor screen and other products. We are committed to providing customers with a full range of LED display solutions.

1. Q: Are you a direct manufacturer and exporter from China?

A: Yes, we are. We have our own factory and international sales department. We design and produce our own products all by ourselves.

2. Q: Where's your factory located?

A: Our factory locates in Shenzhen City, Guangdong Province, China. It takes about 60mins by car from Hongkong International Airport to our factory.

You are warmly welcome to visit our factory anytime.

3. Q: How do I purchase your goods?

A: Please send us enquiries via Whatsapp, or email us, and you can give us a call to tell us your needs, we'll reply you ASAP.

4. Q: What should I provide if I want my own packaging or printing?

A: You can provide your logo and tell us your requirements of packages and we will design and make the sample for confirmation before official orders.

5. Q: How long is the lead time?

A: Usually it takes around 15-20days. If you need the goods urgently, please tell us, and we can will try our best to give you priority.

6. Q: How can I get a sample from you?

A: If we have stock for the models you need, we can send you our stock sample FOC. But if you need your own design, sampling cost will be charged, and for both ways, the courier freight needs to be covered by you. And samples can be sent through Fedex, UPS, TNT, DHL, ect.

 If you have any question, please feel free to contact us for support.
