R16 R16zz 1′ ′ X2′ ′ X1/2′ ′ Bearing R16z Miniature Inch Ball Bearings 25.4*50.8*12.7mm
Ruian Sowinpak. Co., Ltd.- Aligning：Non-Aligning Bearing
- Separated：Unseparated
- Rows Number：Single
- Load Direction：Radial Bearing
- Material：Bearing Steel
- Place of Origin：Shan Dong China (Mainlan
Base Info
- Model NO.：R16 R16ZZ
- Transport Package：as Per Client′s Requirement
- Trademark：Yiding
- Origin：China
- HS Code：8482102000
- Production Capacity：60000 Pieces,Month
Description
TypeDimension (mm) Basic Load Rating (N) Limiting Speed (rpm) Weight (Kg) d D B r (min) Dynamic Static Grease Oil Open Shield R2 3.175 9.525 3.969 3.969 0.15 500 190 36000 45000 0.0016 R3 4.762 12.70 3.969 4.978 0.2 1070 420 32000 40000 0.0020 R4 6.350 15.875 4.978 4.978 0.2 1470 600 26000 34000 0.0044 R4A 6.350 19.05 5.556 7.144 0.2 2800 1060 26000 34000 0.0080 R6 9.525 22.225 5.556 7.144 0.3 3330 1410 19000 26000 0.0110 R8 12.70 28.575 6.35 7.9358 0.3 5120 2390 18000 24000 0.0180 R10 15.875 34.925 7.14 8.730 0.3 6000 3270 17000 22000 0.0370 R12 19.08 41.275 7.938 11.112 0.6 9390 5080 14000 18000 0.0470 R14 22.225 47.625 9.525 12.70 0.6 10070 5810 13000 17000 0.0720 R16 25.40 50.80 9.525 12.70 0.6 10070 5810 12000 16000 0.0850 R18 28.575 53.975 9.525 12.70 1.0 10180 8660 11000 15000 0.0900 R20 31.75 57.15 9.520 12.70 1.0 10180 8660 10000 13000 0.0950 R22 34.925 63.50 11.113 14.288 1.0 12470 9450 8800 10000 0.1050 R24 38.10 66.675 11.113 14.288 1.1 13100 11960 7700 9200 0.1384
