All Size Automobile Prep Bay Booth

Jiaxing Topaz Import & Export Co., Ltd.
  • After-sales Service：1 Year
  • Warranty：1 Year
  • Type：Preparation
  • Certification：CE
  • Substrate：Steel
  • Brand：Longxiang Brand

Base Info

  • Model NO.：LX-6300
  • Coating：Powder Coating
  • Airflow Direction：Cross-flow Type
  • Heating Mode：Without Heating
  • Paint Mist Treatment：Dry-type
  • Condition：New
  • Inside Dimension：6300*3450*2800mm(L*W*H)
  • Outside Dimension：7550*3550*3200mm(L*W*H)
  • Basement：Without Basement
  • Fan System：Centrifugal Fan
  • Lighting System：LED Lighting
  • Voltage：380V,220V
  • Total Power：8.4kw
  • Usage：Car Polishing
  • Name：Prep Station
  • Filtering System：Fiber Glass Filter
  • Glass：Tempered Glass
  • Transport Package：Sea Package
  • Specification：7550*3550*3200mm(L*W*H)
  • Trademark：longxiang brand
  • Origin：China
  • HS Code：8419899090
  • Production Capacity：30 Sets,Months

Description

                     Specification of Prep-station (LX-6300)        Inside dimension6300×3450×2800mm(L×W×H)Outside dimension7550×3550×3500mm(L×W×H)Basement and floorGalvanized steel assemble,height is 300mm,completely grill floorRamp 2 pieces 1750×750×300mm(L×W×H) blueCeiling system6400×3550×520mm(L×W×H),with lights on 2 sides of roof,part of the roof with filter,other small part with air-proof seal plateGenerator setting type2 rows of pits for exhaust air, with quadrate steel frame,white color coated steelExhaust systemGenerator cabin dimension:1300×1100×1900mm(L×W×H);with 1 set 7.5KW fan for exhaust air,belt-drive motor position:outside;with air capacity 20000m³/h,electric damper control intake and exhaust air capacitySeal typeBack side set 50mm EPS,other three sides with PVC soft curtain,curtain color:upper part:white,middle part:transparent,lower part:whiteCeiling installationSteel rope hanging or steel pole supporting the roof(optional)Filter systemFloor filer (fiberglass filter),ceiling filterLighting system8 units×3pcs=24×36WControl systemFan switch,lighting switch and electric damper switchVoltage frequency380V/3PH or 220V/1PH,50HZRoof Single iron sheet bending roofTotal power 8.4KWAll Size Automobile Prep Bay BoothAll Size Automobile Prep Bay Booth
