• Model NO.：DL-ISSL1C-20W
• Illumination Time：12h
• Cell Type：LiFePO4 or Ternary Lithium
• Charging Time (H)：6
• Usage：Garden, Street, Highway
• IP Rating：IP65
• Certification：CE, RoHS, ISO
• Voltage：12,24V
• With Light Source：With Light Source
• Solar Panel：18V 35W High Efficiency Monocrystalline Silicon
• Battery：12V 18ah Lithium Battery
• LED Chips：Bridgelux
• Lumen：2800-3200lm
• Viewing Angle：60*120
• Charge Time：6 Hours in Strong Sunshine
• Working Time：3-5 Continuous Rainy and Cloudy Days
• Working Temperature：-30-60 Celsius
• Colour Temperature：6000-6500K(Standard),2800-3300K,4000-4500K
• Height of Pole：7-9m
• Distance of Light：18-20m
• Certificate：CE(EMC&LVD) & RoHS & IP65
• Lamp Size：92*30*14(Cm)
• Net Weight：9.5kg
• Gross Weight：10.6kg
• Transport Package：Carton,Wooden Frame
• Specification：92*30*14(cm)
• Trademark：DAWN
• Origin：China
• HS Code：9405409000
• Production Capacity：60000units,Year

Model NO.

DL-ISSL1C-20W

DL-ISSL1C-30W

DL-ISSL1C-40W

DL-ISSL1C-50W

DL-ISSL1C-60W

DL-ISSL1C
-70WDL-ISSL1C-80WDL-ISSL1C-100WDL-ISSL1C-120WDL-ISSL1C-150WDL-ISSL1C-200W

LampPower

20W30W40W50W60W70W80W100W120W150W200WLumen2800-3200lm4200-4800lm5600-6400lm7000-8000lm8400-9600lm9800-11200lm11200-12800lm14000-16000lm16800-19200lm21000-24000lm28000-32000lmSolar Panel Power18V 35W18V 60W18V 60W18V 80W18V 80W18V 90W18V 100W18V 120W36V 140W36V 160W36V 200WSolar Panel Type High Efficiency Mono SiliconLED ChipsBridgelux/or other brandsSolar Panel Lifetime25 YearsBattery TypeLiFePO4 Battery with 5-8 Years LifetimeWarranty Years3-5 Years
Product Features?

1.Integrated design,all in?one solar LED street light,?solar panel,Led chips, battery,cotroller,motion sensor,etc,?all in(on) a light,without extra cable,?save shipping cost and labour cost.

2.Easy to? ship,carry and install.

3.Energy saving and environment friendly by perfect combination of solar power and LED lighting.

4.High capacity and long life Lithium battery,5-year theoretical working life and high-temperature resistance, make the whole light a longer life.

5.Safe and reliable rain-proof & water-proof design.

6.Alumina Alloy is used for main structure in order to preventing dusty and corrosion,is also good for heat dissipation.

7.Different power control according to time period, lower brightness when less people after midnight, in order to saving energy and improve practicability.
