Drum Conveyor Bend Pulley (250-1600mm dia)
Xiamen Fuyin Machinery Co., Ltd- Certification：CE, ISO
- Manufacturing Process：Casting
- Material：Carbon Steel
- Surface Treatment：Polishing
- Application：Chemical Industry, Grain Transport, Mining Transport, Power Plant
- Classification：Driving Pulley, Bend Pulley
Base Info
- Driving Pulley Diameter：500-1600mm
- Bend Pulley Diameter：250-1600mm
- Belt Width：500-2400mm
- Transport Package：Standard Packing
- Trademark：PK
- Origin：Henan, China
- HS Code：8428330000
- Production Capacity：5000 PCS, Month
Description
Basic DetailsDriving Pulley/ Head Pulley/ Transmission DrumBend Pulley/ Trail Pulley/ Turnabout DrumPulley Diameterü D=500-1600mm
ü 500/630/800/1000/1250/1400/1600mmü D=250-1600mm
ü 250/315/400/500/630/800/1000/1250/1600mmBelt WidthB=500-2400mmB=500-2400mmClassificationAccording to different carrying capacity, it can
be classified into three types, which have
different bearing apertures.
² Light-duty: 80~100mm
² Medium-duty: 120~180mm
² Heavy-duty: 200~220mmAccording to different carrying capacity, it can
be classified into three types, which have
different shaft diameters.
² Light-duty: 50~100mm
² Medium-duty: 120~180mm
² Heavy-duty: 200~260mmSurface Treatmentü Bare steel surface
ü Herringbone rubber surface
ü Rhombic rubber surface
ü Vulcanized rubber surfaceü Bare steel surface
ü Plain rubber surface
Technical ParametersBelt WidthDriving Pulley DiameterBend Pulley Diameter (mm) (mm)(mm)500500250/ 315/ 400/ 500650500/ 630250/ 315/ 400/ 500/ 630800500/ 630/ 800/ 1000/ 1250/ 1600250/ 315/ 400/ 500/ 630/ 800/ 10001000630/ 800/ 1000/ 1250/ 1600250/ 315/ 400/ 500/ 630/ 800/ 1000/ 1250/ 16001200630/ 800/ 1000/ 1250/ 1600250/ 315/ 400/ 500/ 630/ 800/ 1000/ 1250/ 16001400630/ 800/ 1000/ 1250/ 1600315/ 400/ 500/ 630/ 800/ 1000/ 1250/ 16001600630/ 800/ 1000/ 1250/ 1600400/ 500/ 630/ 800/ 1000/ 1250/ 16001800630/ 800/ 1000/ 1250/ 1600400/ 500/ 630/ 800/ 1000/ 1250/ 1600
ü 500/630/800/1000/1250/1400/1600mmü D=250-1600mm
ü 250/315/400/500/630/800/1000/1250/1600mmBelt WidthB=500-2400mmB=500-2400mmClassificationAccording to different carrying capacity, it can
be classified into three types, which have
different bearing apertures.
² Light-duty: 80~100mm
² Medium-duty: 120~180mm
² Heavy-duty: 200~220mmAccording to different carrying capacity, it can
be classified into three types, which have
different shaft diameters.
² Light-duty: 50~100mm
² Medium-duty: 120~180mm
² Heavy-duty: 200~260mmSurface Treatmentü Bare steel surface
ü Herringbone rubber surface
ü Rhombic rubber surface
ü Vulcanized rubber surfaceü Bare steel surface
ü Plain rubber surface
Technical ParametersBelt WidthDriving Pulley DiameterBend Pulley Diameter (mm) (mm)(mm)500500250/ 315/ 400/ 500650500/ 630250/ 315/ 400/ 500/ 630800500/ 630/ 800/ 1000/ 1250/ 1600250/ 315/ 400/ 500/ 630/ 800/ 10001000630/ 800/ 1000/ 1250/ 1600250/ 315/ 400/ 500/ 630/ 800/ 1000/ 1250/ 16001200630/ 800/ 1000/ 1250/ 1600250/ 315/ 400/ 500/ 630/ 800/ 1000/ 1250/ 16001400630/ 800/ 1000/ 1250/ 1600315/ 400/ 500/ 630/ 800/ 1000/ 1250/ 16001600630/ 800/ 1000/ 1250/ 1600400/ 500/ 630/ 800/ 1000/ 1250/ 16001800630/ 800/ 1000/ 1250/ 1600400/ 500/ 630/ 800/ 1000/ 1250/ 1600
