Cylindrical Roller Bearing Single Row 300*460*74mm Nu1060
Kunshan Shenkai Precision Mould Co., Ltd.- Rolling Body：Roller Bearings
- The Number of Rows：Single
- Outer Dimension：Extra Large (440mm)
- Material：Bearing Steel
- Spherical：Non-Aligning Bearings
- Load Direction：Radial Bearing
Base Info
- Model NO.：NU1060
- Separated：Unseparated
- Product Name：Single Row 300*460*74mm Nu1060 Cylindrical Rolle
- Size：300X460X74mm
- Weight：0.27kg
- Basic Dynamic Load Rating：858kn
- Basic Static Load Rating：1370kn
- Fatigue Load Limit：129kn
- Reference Speed：1500r,Min
- Limiting Speed：2000r,Min
- Calculation Factor：0.15
- Vibration：Zv1, Zv2, Zv3, or as Requested
- Transport Package：Single Box Packaging,OEM
- Specification：300x460x74mm
- Trademark：TFN,OEM,SEMRI
- Origin：China
- HS Code：8482500090
- Production Capacity：10000,Month
Description
Quality Control Process 1.Assembly 2.Windage test2.Windage test 3.Cleaning 4.Rotary test 5.Greasing and gland 6.Noise inspection 7.Appearance inspection 8.Rust prevention 9.Product packaging Application low noise machine,automobile,motorcycle,and the general machinery and etc.
Limiting speeds(rpm)Mass(Kg) d D B rs min rs1 min Cr Cor Grease Oil (Approx.) NU10 Series NU1005 25 47 12 0.6 0.3 15.1 14.1 16,000 19,000 0.092 NU2211E 55 100 25 1.5 1.1 97 114 5,600 6,600 0.968 NU2212 60 110 28 1.5 1.5 96 116 5,800 6,800 1.06 NU2212E 60 110 28 1.5 1.5 131 157 5,200 6,100 1.21 NU2213 65 120 31 1.5 1.5 120 149 5,400 6,300 1.4 NU2213E 65 120 31 1.5 1.5 149 181 4,800 5,600 1.6 NU2214 70 125 31 1.5 1.5 119 151 5,000 5,900 1.47 NU2214E 70 125 31 1.5 1.5 156 194 4,500 5,200 1.7 NU2215 75 130 31 1.5 1.5 130 162 4,700 5,500 1.55 NU2215E 75 130 31 1.5 1.5 162 207 4,200 4,900 1.79 NU2216 80 140 33 2 2 147 186 4,400 5,100 1.93 NU2216E 80 140 33 2 2 186 243 3,900 4,600 2.12 NU2217 85 150 36 2 2 170 218 4,100 4,800 2.44 NU2217E 85 150 36 2 2 217 279 3,700 4,300 2.68 NU2218 90 160 40 2 2 197 248 3,900 4,600 3.1 NU2218E 90 160 40 2 2 242 315 3,500 4,100 3.33 NU2219 95 170 43 2.1 2.1 230 298 3,600 4,300 3.79 NU2219E 95 170 43 2.1 2.1 286 370 3,300 3,800 4.14 NU2220 100 180 46 2.1 2.1 258 340 3,500 4,100 4.57 NU2220E 100 180 46 2.1 2.1 335 445 3,100 3,600 5.01 NU2222 110 200 53 2.1 2.1 320 415 3,100 3,700 6.56 NU2222E 110 200 53 2.1 2.1 385 515 2,800 3,300 7.4 NU2224 120 215 58 2.1 2.1 350 460 2,900 3,400 8.19 NU2224E 120 215 58 2.1 2.1 450 620 2,600 3,000 9.18 NU2226 130 230 64 3 3 380 530 2,600 3,100 10.2 NU2226E 130 230 64 3 3 530 735 2,300 2,700 11.8 NU2228 140 250 68 3 3 445 635 2,400 2,800 12.9 NU2228E 140 250 68 3 3 575 835 2,100 2,500 15.8 NU222E 110 200 38 2.1 2.1 293 365 3,100 3,700 4.27 NU2230 150 270 73 3 3 500 710 2,200 2,600 16.3 NU2230E 150 270 73 3 3 660 980 2,000 2,400 19.7
Limiting speeds(rpm)1.Q:Are you a factory or trading company?
A:SEMRI Bearing is specialized in manufacturing and exporting bearings.
SEMRI Bearing have own factory and warehouse.
2.Q:Can I get some samples and do you offer the sample free?
A:Yes, sure, SEMRI Bearing are honored to offer you samples.Can you buy a ticket ?3.Q:What is the payment?
A: 30% T/T In Advance, 70% T/T Against Copy Of B/L
B: 100% L/C At Sight
4.Q:What is the MOQ for bearing?
A: SEMRI Bearing MOQ is 1 pc.
5.Q:What kind of service you can offer?
A:Technology support;Installation guidance;OEM
