Aluminum Air Suspension Tank Air Suspension Source Kit
Shenzhen Zhongtaijia Packaging, Co. Ltd- After-sales Service：1 Year Warranty
- Warranty：1 Year Warranty
- Material：Copper, Iron, Aluminum, Plastic
- Certification：ISO,TS16949, ISO9001
- Car Make：Carteeair
- OEM：Yes
Base Info
- Model NO.：TANK
- Type：Air Suspension Compressor
- Color：Black,Polished,Anodized
- Size：1-5gallons
- Transport Package：Box
- Trademark：CARTEEAIR
- Origin：China
Description
| Air Tank Specifications: | |||||||||
| Name | Length mm | Diameter mm | Height mm | Port 1/4NPT | Port 3/8NPT | Port 1/2NPT | NW/GW kg | Packing cm | |
| 1Ga 5 Ports | 300 | 168 | 190 | 3 | 2 | 1.9/2.4 | 31x19x19 | ||
| 1.5Ga 5Ports | 360 | 168 | 190 | 3 | 2 | 2.2/2.7 | 37x19x19 | ||
| 3Ga 5 Ports | 605 | 168 | 190 | 3 | 2 | 3.5/4.0 | 61x17.5x20 | ||
| 5Ga 5Ports | 850 | 168 | 190 | 3 | 2 | 4.9/5.5 | 86x17.5x20 |
CAUTION! DO NOT PRESSURIZE YOUR TANK UNTIL YOU HAVE INTALLED ALL NECESSARY PORT FITTINGS AND ACCESSORIES.
- Apply sealant to threads of fittings prior to assembly and tighten each part with a wrench.
- Do not over tighten if your port fittings are made from brass, since brass threads can be stripped. The fittings need to be only air tight.
- Always release air from tank before servicing or repairs.
WARNING: DRAIN TANK AFTER EACH USE. FAILURE TO DRAIN TANK AND REMOVE CONDENSATION WILL CAUSE TANK TO RUST PREMATURELY.
- To remove any accumulated condensation inside the tank, bleed pressure from tank until pressure is approximately 5psi to 20 psi.
- If drain cock valve is plugged, release all air pressure from tank, remove drain valve and clean, then reinstall.
