P10 WiFi/RS485/4G LED Sign Indoor Outdoor LED Scrolling Display Message Board
Dongguan Sowo Packaging Materials Co., Ltd.- Tube Chip Color：Dual-color
- IP Rating：IP65
- Pixel Pitch：10mm
- Pixel Configuration：1r, 1g
- Display Function：Video Display, Image & Text Display, Text Display, Market Display
- Average Power Consumption：300
Base Info
- Model NO.：P10 DIP Led display
- Pixel Density：10000 dot , m²
- Scanning Mode：Static Scan
- Display Type：LED Dot Matrix Display
- Application：Eunnel, Urban Roadxpressway T
- Certification：CE, RoHS, CCC
- Brightness：7000
- Module Size：160X320
- Visual Angle：70
- Packaje：347
- Module Current/(a)：3
- Hub Port：12
- Transport Package：Wooden Carton
- Specification：16*32
- Trademark：GLG-LED
- Origin：China
- HS Code：8531200000
- Production Capacity：50000PCS,Month
Description
• Display module having the versatility and interchangeability can be composed of different display colors and different sizes according to needs.
• Double-box structure, the formation of internal natural convection mode, so cabinets space temperature reaches equilibrium.
• Pixel module junction box and use the "O"ring, with good moisture anti-leakage performance.
• Module package uses advanced soft silicone, the elastic, strong anti-aging ability.
• Power supply, it is important IC device through the heat sink cooling, not only solve the heat, but also to ensure the performance is unstable due to mechanical failure when the cooling fan caused.
• Use special wide temperature range of the device, ensure the normal operation of the display at high or low temperatures.
The control system only with the IPC, and higher reliability.
• Use of sophisticated large-scale integrated chip high-speed serial transmission network alternative to discrete parallel transmission chip, reducing the complexity ofthe transmission display, reducing the complexity of the control system to improve the stability of the product.
• Using the network cable to transmit data to reduce the screen body inside the transmission cable, greatly improve the stability of the display.
• Using a common network data transmission technology, improve gradation display variable message signs, information boards enable a better display.
• Using a common network data transmission technology, in favor of compatibility and product upgrading. Help to improve the response speed of the system variable message signs.LED variable message signs screen perform the following national standardsLED variable message screen GB/T 23828-2009 fully in accordance with international design,
production and testing Traffic sign display GB 5768.2 traffic sign text, graphics meet the standards Chinese character display GB 2312 digital display standard Chinese characters Shell protection grade GB 7000.1 IP65 protection rating Communication interfaces and protocols JT/T606.1 and JT/T606.3 standard asynchronous
Quality Control Process
Package Method
Project Case
Contact
Shenzhen Glare-LED Optoelectronic Co., Ltd
Add: 1-4 floor, B2 building,No. 10 Tongqing Road,TongXin village,Baolong avenue,Longgang District,Shenzhen City,Guangdong province,China
P.C: 518116
