P3 Indoor Full Color Front Maintenance LED Display Screen
Jiaxing Topaz Import & Export Co., Ltd.- Tube Chip Color：Full Color
- Display Function：Video Display, Image & Text Display, Text Display, Market Display
- Pixel Pitch：3mm
- Pixel Configuration：1R,1G,1B
- Pixel Density：111111DOT,M2
- Scanning Mode：1,32 Scan
Base Info
- Model NO.：P3
- System Operating Platform：Win8,Win10
- Display Type：LED Video Display
- Application：Stage Performance, Advertising, Shopping Guide
- IP Rating：IP43
- Certification：CE, RoHS, UL, CCC, ETL
- Module：192*192mm
- Cabinet Size：480*480mm
- Transport Package：Wood Box Packing
- Specification：960*960mm
- Trademark：OSCARLED
- Origin：Shenzhen China
- HS Code：8528591090
- Production Capacity：500m2,M
Description
Chapter 1 Specification and main technical index(1)Construction Description 1,Screen consists of cabinets ,cabinet consist of modules
2,modules consist of pixels and each pixel contains 1R1PG1PB total of 1 LED lamps (2)Professional analysisNo.Professional analysis contentAnalysis item1Color matching analysisTo make color matching reach the best white balance effect,the color matching rate of different color brightness is R:G:B/3:6:1(SMD2121)(3)Pixel ParameterNo.ItemParameter1Pixel pitchPH3mm 2Pixel configuration1R 1PG 1PB(4)Tube Chip ParameterNo.ItemWavelengthBrightness1Red tube chip620-625nm800-1000mcd2Pure green tube chip520-525nm2200-3000mcd3Pure blue tube chip465-470nm300-600mcd(5) Electricity parameter1Pixel density(dots/M2)1111111dots/ m²2White Balance Brightness≥1100 (cd/m²)3Brightness Adjusted256 grade automatically, 8 grade manually4Color temperature(K)5000-95005View AngleHorizontal:140°; Vertical: 110°6Best viewing distance(m)3-30m7Communication distance120 meters by LAN cable(without relay)(optical fiber transmission 500M-10000M)8Drive Method1/32scan constant current 9Gray Grades16384 levels for each color10Display Color16,777,21611Refresh Frequency (Hz)≥384012Control ModeYnchronous controller13Signal interfaceDVI14Input signalVideo: PAL/NTSC etc15Display format800 * 600,1024 * 768, 1280*102416SoftwareSupport windows series system17WaterproofNo18ProtectionIP4319Working temperature(ºC)(-20ºC~+60ºC )20Humidity(RH)10%-90%RH21LED Lifetime(hours)≥100,00022Whole Display FlatnessLess than 1mm Juncture23Power ConsumptionAverage:≤250w/m²;Maximum: ≤1000w/m²24Operating VoltageAC100V±220V 50~60HZ25Operating PlatformWINDOWS(WIN10,WIN8, WIN XP)
