HD Advertising with P4 Full Color Indoor LED Display Screen
Panhong Chemical Co., Limited.- Tube Chip Color:Full Color
- IP Rating:IP43
- Pixel Pitch:4mm
- Pixel Configuration:1R, 1G, 1B
- Display Function:Video Display
- Average Power Consumption:500W,M2
Base Info
- Model NO.:p4- Indoor
- Pixel Density:62500dots,M2
- Scanning Mode:1,16 Scan
- Display Type:LED Video Display
- Application:Advertising
- Certification:CE, RoHS, UL, CCC, ETL, SGS ISO
- Product:P4full Color LED Display
- Size of Module:256*128mm
- Brightness:1800CD,Sqm
- Waterproof:IP43 Front, IP43back
- Warranty Time:3-5years
- Item:Waterproof Video LED Display
- Best Viewing Distance:4-150 M
- Colors:More Than 16.7m Colors
- Mtbf:10000 Hours
- Life Span:More Than 100, 000hours
- Transport Package:1.Wooden Package.2.Air Flight Case3.Carton Package
- Specification:CE&ROHS&UL&FCC&SGS&3C
- Trademark:FOXGOLDEN
- Origin:Shenzhen, China
- HS Code:8528591090
- Production Capacity:4000sqm,Month
Description
Technical parameterUnit moduleModule size256*128mmPixel pitch4mmPixel density62500dots/m2Pixel configuration1R1G1BLed specificationΦ 3ellipsePixel resolutionW: 64dots*H: 32dotsCabinetDimension768mm*768mm*100mmQuantities of module18pcsPower supply2pcsThermal dischargeFan*2pcsTotal weight50kgBest viewing angle4-150mTemperatureStorage: -35degree~+85degreeWorking: -20degree~+80degreeThickness11cm can adjustableRemarks: cabinet size can changed, upon project need.PowerWorking voltageAC220V/110V± 10%Average power consumption600WMax. Power consumption≤ 1100W/sqmCurrent≤ 20mA(single LED)Control systemCPUPentium4 or aboveOperating systemWIN98/2000/NT/XPControl methodSynchronizationMain technical parameterDriving device1/16scanningDrive typeConstant Current driver ICRefresh frequency≥ 400HzGrey scale/colors256 levels of each color(R/G/B)/16.7M colorBrightness of white balanceMore than 9000cd/sqmBrightness adjustment256 levels of each color(R/G/B)by softwareOperating ambient humidity10%--95%Video signalPAL/NTSCControl systemDVI display card+full color controller cardMTBF≥ 10, 000hoursLife span≥ 100, 000hoursFlatnessTolerance of interpixel ≤ 0.3mmTolerance of modules clearance≤ 0.6mmPower switchAutomatic switchDisplay mode1024*768SoftwareLED media player





RFQ:
Q:What is your hot sale product?
A:P10 full color is best selling for Outdoor; P6 full color is best selling for indoor.
Q:What different from 1/4 scaning with 1/8 scaning?
A:1/4 scaning is better than 1/8, the screen will be high definition,high brightness.
Q:What different from LCD with LED?
A:1.LED is more energy save than LCD , have a high definition .
2.LED have a big viewing angle, it can up to160 degree.
3.LED can working well in a strong shine day.
Q:How to ensure the good quality of LED display?
A:Optimized structure can improve the efficency of installing screen to creat value;Aging can improve the quality, ensure reliability.
Q:The advantage of LED SMD
A:1.High resolution ;2.Big viewing angle; 3.Rugged ; 4.Vivid Mixture Color Effect ;5.Color Consistency; 6.Enhanced Contrast Ratio;7.Mass Production; 8.Long Service Life.
Foxgolden Group Ltd
Address: No.57,Shuitian Fourth Industrial Park,Shiyan Town,Baoan District,Shenzhen City,China
Foxgolden had been engaged in designing and manufacturing LED display for more than 11 years. Our products have certificates like CE/FCC/RoHS/NQA /SGS/ISO.
The best quality products and excellent service will be provided to you by our professional team.
