Factory Supply Dental Equipment Dental Portable X Ray Unit Dental X-ray Machine
NINGBO SONGROCK TECH. CO., LTD.- Applicable Departments：Oral Department of Internal Medicine
- Certification：CE
- Type：X-Ray Equipment
- Material：PVC
- Voltage：70kv
- Tube Current：2mA
Base Info
- Model NO.：CarryX-II-S
- Tube：Japanese Canon Tube
- Light Weight：1.9kg
- Focus Spot Size：0.4mm
- Safe：Low Radiation
- Battery：Rechargeable
- Time Exposure：0.04-2.0s
- High Frequency：30kHz
- Radiation Leakage：<0.25mgy,H
- Transport Package：Carton Box
- Specification：27*21*21cm; 3kg
- Trademark：Carry. X
- Origin：China
- HS Code：90184990
- Production Capacity：500units,Month
Description
Basic Info.
Model NO. CarryX-II-S Tube Japanese Canon Tube Light Weight 1.9kg Focus Spot Size 0.4mm Safe Low Radiation Battery Rechargeable Time Exposure 0.04-2.0s High Frequency 30kHz Radiation Leakage <0.25mgy/H Transport Package Carton Box Specification 27*21*21cm; 3kg Trademark Carry. X Origin China HS Code 90184990 Production Capacity 500units/MonthProduct Description
Factory Supply Dental Equipment Dental Portable X Ray Unit Dental X-Ray MachineTechnical Data
| Tube Voltage | 70kV±10% |
| Tube Current | 2mA±20% |
| Charge input Voltage | 100V-240V |
| Frequency | 50Hz-60Hz |
| X- Tube | Canon D-045 |
| Anode Angle | 12.5° |
| Focus | 0.4mm |
| Exposure time range | 0.04s - 2.0s |
| Leak Emissivity | 1 meter≤0.25mGy/h |
| Machine Weight | 1.7kg |
| Relative Humidity | 30%RH~75%RH |
Features
★A true high frequency chair side x-ray machine, ensure less radiation for patient & operator with superior image quality.
★The circuit components imported from South Korea adopt high-frequency closed-loop control; imaging will not be affected even if the battery power is low.
★Adopt Canon micro focus tube with focus 0.4mm, anode angle of 12.5°.
★Less exposure time, only about 0.4s, which is 5-8 times shorter than ordinary portable x-ray, less radiation dose, and avoid hand shake causing the blurry image.
★Light in weight, only 1.7kgs. Compact & single handed operational device.
★Wide digital display for easy operation.
★150 shots in a complete charge.
★2mA tube current, combines higher performance, and high definition imaging.
★Korea Technology PCB
★Adopts Japan SONY Lithium battery, longer life-span
★Needs to charge 3-4hours, and it can be used 150-200 times once charged full power, and the battery can be charged about 300 times.
