• Model NO.：DXSLP-001
• Voltage：85-265V
• Certification：CE, RoHS, CCC, ISO9001
• Height：3m 3.5m 4m 4.5m
• Color：Matt Black
• Lamp Source：70W 150W Metal Halide Lamp
• Place of Origin：Jiangsu, China (Mainlan
• Lamp Source Brand：Yamin
• Metal Protection：Hot Dipped Galvanized
• Transport Package：Use Plastic Foam
• Specification：CE SGS ROHS FCC ISO
• Trademark：DX (Dingxin)
• Origin：Yangzhou China
• HS Code：54094090
• Production Capacity：50000PCS,Month

Basic Info.

Model NO. DXSLP-001 Voltage 85-265V Certification CE, RoHS, CCC, ISO9001 Height 3m 3.5m 4m 4.5m Color Matt Black Lamp Source 70W 150W Metal Halide Lamp Place of Origin Jiangsu, China (Mainlan Lamp Source Brand Yamin Metal Protection Hot Dipped Galvanized Transport Package Use Plastic Foam Specification CE SGS ROHS FCC ISO Trademark DX (Dingxin) Origin Yangzhou China HS Code 54094090 Production Capacity 50000PCS/Month

Product Description

Applications:
Compound wall light, Security lighting,Park lighting, Walkway lighting, Residential street lighting, Square, Garden,Highway,etc.

Advantage:
1.The pole patterns are standardized type, practical and economical, which can also be customized as per client's specific requirement.

2.Durable, shockproof; Safe: environmentally friendly. The optimized heat sink design to ensure  the LED junction temperature is below60 degrees

3.Designed to provide soft, anti-glare and effective ambient

4.Lighting using high brightness LED light source and special anti-glare design

 Trade terms
1.30% advanced payment by T/T or L/C, 70% T/T payment before shipment.

2. Production lead time for 100~500PCS: 7-15days, 500~1000PCS: 15-20days

3. Sample can be delivered in 7days

4. Shipping freight are quoted under your requests

5. Shipping port: Shanghai, Mainland China

6. Discounts are offered based on order quantities
ODM & OEM WELCOMED
1.Send us drawings of your solar street lighting system, we will work out satisfactory solutions for you.

2.Tell us the consumption/lighting power or the road condition/width, we will work out satisfactory solutions for you.

Pole	Material: Q235 or die-cast aluminum Height: 2-6m Thickness: 2.5mm,2.75mm, 3mm Finish: Hot-dip Galvanize, powder coating Fastener:Made of stainless steel with high intensity and corrosion protection. Life span: 25years Details see CAD drawing of poles of different cases
Light	Power:5-20W energy-saving light, LED light Working temperature: -60 to +70 centigrade IP rating: IP65 Working life: >50000hours
Solar panel	Power 15-90W Mono-crystalline panel or Polycrystalline panel Power tolerance : ±5% Cell efficiency:15%-17% Working temperature:  -40°C to 85°C working life ≥ 20 years
Battery	Solar Gel Battery (12V & 24V) l Chinese leading manufacture of solar gel battery l Maintenance-free Gel battery l Long life span: Gel electrolyte - no acid layer, no leaking l Echo-friendly: No Cadmium. No leaking  l Working temperature: -40 to +50 centigrade l Easy transportation with no leaking of battery l working life ≥ 3 years
Battery box	Waterproof   Anti-corrosion   Pressure resistant   Heat protection   Life span: 20years
Controller	Intelligent sensor of  l Light control l Time control  l Power control l Over charging protection l Discharging protection l Short Circuit protection l Reverse polarity protection



Input voltage	DC12V/24V
Light	LED Chip: Epistar ,Bridgelux or Cree
Light Body	Made of Aluminum
Diffuser	PC or PMMA
lampholder	E27,E40...
Initial Luminous flux	6000lm~18000lm
Color temperature	5500K
Color Rendering Property	Ra>75%
Beam angle	>120°on 0°-180°flat surface & >60°on 90°-270°flat surface
Illuminate range	18lux~38lux
Lamp lifespan	50000hs
