• Model NO.：p10 -20140602
• Pixel Density：10000 DOT , M², 10, 000dots,M2
• Scanning Mode：1,8 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, UL, CCC, ETL
• Brightness：More Than 8000CD,Sqm
• Waterproof：IP67 Front, IP65back
• Warranty Time：7years
• Colors：More Than 16.7m Colors
• Life Span：More Than 10, 000hours
• Module Size：160*160mm
• Driving Device：Synchronization
• Best Viewing Distance：8-150m
• Transport Package：1.Wooden Package.2.Air Flight Case3.Carton Package
• Specification：CE&ROHS&UL&FCC&SGS&3C
• Trademark：FOXGOLDEN
• Origin：Shenzhen, China
• HS Code：853120
• Production Capacity：5000sqm,Month

Technical  parameterUnit  moduleModule  size160*160mmPixel  pitch 10mmPixel  density10, 000dots/m2Pixel  configuration1R1G1BLed  specificationΦ 3ellipsePixel  resolutionW: 16dots*H: 16dotsCabinetDimension960mm*960mm*110mm Quantities  of  module36pcsPower  supply6pcsThermal  dischargeFan*2pcsTotal  weight50kgBest  viewing  angle10-100mTemperatureStorage:   -35degree~+85degreeWorking:   -20degree~+80degreeThickness11cm  can  adjustableRemarks:   cabinet  size  can  changed,   upon  project  need.PowerWorking  voltageAC220V/110V± 10%Average  power  consumption600WMax.   Power  consumption≤ 1000W/sqmCurrent≤ 20mA(single  LED)Control  systemCPUPentium4  or  aboveOperating  systemWIN98/2000/NT/XPControl  methodSynchronizationMain  technical  parameterDriving  device1/4scanningDrive  typeConstant  Current  driver  ICRefresh  frequency≥ 400HzGrey  scale/colors256  levels  of  each  color(R/G/B)/16.7M  colorBrightness  of  white  balanceMore  than  9000cd/sqmBrightness  adjustment256  levels  of  each  color(R/G/B)by  softwareOperating  ambient  humidity10%--95%Video  signal PAL/NTSCControl  systemDVI  display  card+full  color  controller  cardMTBF≥ 10, 000hoursLife  span≥ 100, 000hoursFlatnessTolerance  of  interpixel  ≤ 0.3mmTolerance  of  modules  clearance≤ 0.6mmPower  switchAutomatic  switchDisplay  mode1024*768SoftwareLED  media  player
