Modern Lab Furniture Science Lab Furniture Lab Fume Hood

Nanan Shuitou Town Zhongda HF Welder Factory

Material：Painted Steel
Type：Bypass Type
Function：Exhaust, Velocity Control, for Chemical Experiments
Feature：Corrosion Resistance, Heat Resistant, Acid & Alkali Resistant, Fireproof, Explosion Proof
Hood Type：Standard
Color：Optional

Base Info

Model NO.：PWQG-TF12
Customized：Customized
Condition：New
Other Type：Walk-in Fume Hood
Worktop：Phenolic Resin, Epoxy Resin, Ceramic etc
Other Material：PP, FRP, Stainless Steel etc
Transport Package：Bubble Film+Hard Cotton+Wooden Package
Specification：1200,1500,1800*850*2350mm
Origin：China
HS Code：940320000
Production Capacity：1000 Sets , Year

Description

Type Benchtop fume hoodsExhaust systemCAV exhaust system (Constant air volume)Exhaust fanInclined flow fan (The installation principle is the same as air conditioning)Exhaust air rate1500-3500m3/hVentilation ductsPVC material, FPR, PP or otherPower(Single-phase) 220V/50HZ or (Three-phase) 380V/50HZAir valveManual or electricAverage wind speed0.3-0.6m/s adjustalbeNoise level< 60dB(A)Tops12.7/16/19/mm thickness of Phenolic resin (Other: Epoxy resin, Ceramic etc)Inner LinerUsing HPL physiochemical board to make for lining plate and the flow guide plate

Cabinet

1.0mm thick cold-rolled steel with 75μm epoxy resin powder coating, most chemical resistant

Size

1200/1500/1800*850*2350 mm

Visual windows

Transparent tempered glass, explosion-proof (manual)

Opening height20-700 mm

Control panel

Touch, intelligent control panel (can control lights, sockets, exhaust fan etc)

Gross weight 280-400 kgMotor power0.5-1.1KWLuminance>300LXLab accessoriesPegboard, sink, faucet, gas fitting, sockets, lab stools etc
