P6 Outdoor Full Color LED Display for Outdoor Advertisement
Qingdao Dinghui Refrigeration System Supply Co., Ltd.- Tube Chip Color：Full Color
- IP Rating：IP65
- Pixel Pitch：6mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display, Image & Text Display, Text Display, Market Display
- Average Power Consumption：350W , m²
Base Info
- Model NO.：P6
- Pixel Density：27777
- Scanning Mode：1,8 Scan
- Display Type：LED Video Display
- Application：Advertising
- Certification：CE, RoHS, CCC
- Brightness：More Than 6500 CD
- Mini Order：1 Sqm
- Standard Cabinet Size：1920mm X960mm X 150mm
- Packed：Wooden Case or Flight Case
- Cabinet Material：Die Cast Alumium or Steel
- Gurantty：2 Year
- Transport Package：Wooden Case
- Specification：1920mm X960mmx80mm
- Trademark：NVD
- Origin：Made-in-China
- HS Code：8528591090
- Production Capacity：1000 Sqm, Month
Description
Outdoor fix installation LED DisplayPixel Pitch 5mm 6mm 8mm 10mm Pixel density(dot/m2) 40000 27777 15625 10000 Brightness (nits) ≥5500 ≥5500 ≥6000 ≥6000 Drive Method 1/8 1/8 1/4 1/2 Refresh rate (HZ) ≥1200 Module size (mm) 160x160 192X192 256X128 320X160 Cabinet size (mm) Customize, integer multiples of module size Cabinet material Steel Cabinet weight 50kg/sqm Screen work Voltage (V) 110~240V/AC Screen power consumption
(W/SQM) Max 750 / Average250 Max 750 / Average250 Max 720 / Average 240 Max 720 / Average 240 Screen View angle 140°/140° IP Grade Front IP65/ Rear IP54 Operationg Temperature/Humidity -20~50ºC
10~90% RH Storage Temperature/Humidity -40~60ºC
10~90% RH Life Time 100,000 hours Signal Iput (with video processor) AV ,S-video, VGA, DVI , HDMI, SDI, DP Certification CEROHS CCC ISO
