• Model NO.：SMD p8
• Pixel Density：15625dots,Sqm
• Scanning Mode：1,8 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS
• Physical Pixel Pitch：8mm
• Brightness：≥ 3000 CD,M 2
• Control System：Linsn,Xixun,Colorlight,Nova,Listen
• Module Size：256*128mm
• Operating Temperature：-20°c~50°c
• Transport Package：1.Wooden Package.2.Air Flight Case3.Carton Package
• Specification：CE&ROHS&UL&FCC&SGS&CCC
• Trademark：FOXGOLDEN
• Origin：Shenzhen, Guangdong, China
• HS Code：8528591090
• Production Capacity：2000 M²


Pixel
Physical pixel pitch: 8 mm
Pixel configuration: 1R1G1B

Chip
Wave
Brightness
Packing
R
Opto
620-625nm
250-350mcd
SMD3528
G
Silan
525-530nm
600-700mcd
SMD3528
B
Silan
465-470nm
100-150mcd
SMD3528
Module
Module resolution: 32*16 pixels
 Module size:   256*128 mm
Cabinet
Physical resolution: 128*98 pixels
Cabinet size:   1024*768*(100-120) mm
Physical density: 12288 pixels/cabinet
Module quantity:   pcs = 4 (w) x 6 (h)
Material: Steel
Weight: 32 Kg
Electricity parameter
Brightness: ≥   3000 cd/m 2
Brightness adjusted: 100 grade by software, or by Auto-optic induced
Color processing: 16bit
Display color: 280 trillion
Color temperature(k): 5000_ 9500 (choice by user)
Physical density:   15625 pixels/m 2
Whole display flatness: ≤ 1mm juncture
Best view distance: ≥   13m
Best view angle: Horizontal ± 140° , Vertical ± 140°
Storage temperature: -35° C ~ +85° C Working temperature: -20° C ~ +50° C
Driving method: Constant driving current  Scan: 1/8
Refresh frequency: ≥ 2000Hz
Frame rate: ≥ 60Hz
Humidity(RH): ≤ 90~95%
Protection grades                  : IP65
Working Voltage: DC 5V
Power supply: AC 110 / 220V, 50/60Hz
Average power consumption: 400 w/m 2
Max power consumption: 800 w/m 2
MTBF: 10, 000 hours
Screen lifetime: 100, 000 hours
Control system
Control system: Linsn
Signal interface: DVI
Communication distance: Internet cable: ≤ 100m  Fiber cable: 1000m
Signal transfer mode: Pixels to pixels display synchronized
