LDPE Expansion Catheter with Hole Variable Diameter
Qingdao Great Won Trading Co., Ltd.- Type：Medical Wristbands,Bracelets
- Material：Plastic
- Ethylene Oxide Sterilization：Ethylene Oxide Sterilization
- Quality Guarantee Period：One Year
- Group：Adult and Children
- Logo Printing：With Logo Printing
Base Info
- Model NO.：LDPE
- Certification：CE, ISO13485
- Application：Hospital
- Feature：Disposable
- Transport Package：Double Layer PE Bag
- Specification：0.3mm and 16.0mm
- Trademark：BOVA
- Origin：China
- HS Code：3917320000
- Production Capacity：50000,Week
Description
Basic Info.
Model NO. LDPE Certification CE, ISO13485 Application Hospital Feature Disposable Transport Package Double Layer PE Bag Specification 0.3mm and 16.0mm Trademark BOVA Origin China HS Code 3917320000 Production Capacity 50000/WeekProduct Description
Logo PrintingWith Logo PrintingColorBlue/Whiter or CustomizedHardness60A~80dSizeOd:0.8mm~20.0mm; ID:0.2mm~19.0mmWall Thickness0.05mm~3.0mmTolerance+/-0.05mmShapeSingle Lumen/ Mutil LumenRadiopacityBarium SulphateTrademarkBOVATransport PackageDouble Layer PE BagSpecification0.3mm and 16.0mmOriginChinaHS Code3917320000| Material Name | HDPE (Hi-Density Polyethylene ) |
| Characteristics of PEBAX | HDPE is an HCPP and non-polar thermoplastic resin, the feature is milk white, but it is semi- transparent on the shabby scarf. 1.The highest operation temperature: 66ºC(short time)/ 54ºC(long time );2.The lowest operation temperature: -40ºC; have strong anti-chemical characteristic, and anti-irradiation of sunshine and ultraviolet ray; |
| Other characteristics | anti- water; good anti-penetration of water vapor; it is easy become yellow under gamma ray irradiation. |
| Size of PP tube | inner Diameter: 0.7mm~10.00mm Thickness Wall: 0.20mm~2.00mm Deviation: ±0.05mm~±0.150mm |
| Alternative Material | Medical grade (USP Class VI); Food grade (FDA) and Industrial Grade; |
| Extra value Service | 1.Assignable of the Tube color and size; 2.develop condition: add 20~40%Baso4 |
| Application of range | Packaging tube materials for Various medical guide wire, Instrument connecting tube; structural tube, |
Material Characteristic:
| HDPE | LDPE | PA12 | PEBAX | TPU | PP | |
| Density | 0.96 | 0.93 | 1.15 | 1.01 | 1.2-1.25 | 0.88 |
| Rigidity | 60D-65D | 48D-53D | 68D-70D | 23D-72D | 60A-75D | 60-69D |
| Max. Operation temperature | 54ºC | 54ºC | 80ºC | 80ºC | 80~100ºC | 80~100ºC |
| Min. Operation temperature | -40ºC | -40ºC | -40ºC | -20ºC | -35ºC | -20ºC |
| Tenacity | Commonly | good | commonly | commonly | Excellent | commonly |
| Color | Milk White | Translucent | Translucent | Transparent | Transparent | Translucent |
| Reprocessing performance Characteristics | Commonly | Easy | Easy | Easy | Easy | Commonly |
| Chemical Resistance | Good | Good | Good | Good | Commonly | Good |
| Insulation | Good | Good | Good | Good | Good | Good |
| Biocompatibility | Good | Good | Excellent | Excellent | Excellent | Good |
| Medical Grade Attestation | Yes | yes | yes | yes | yes | yes |
