9 Inch Slewing Drives Used for Material Handler
Linyi Lefu International Trade Co., Ltd.- Feature：Cold-Resistant, Corrosion-Resistant
- Step：Single-Step
- Layout：Cycloidal
- Openness：Closed
- Installation：Vertical
- Transmission Form：Worm
Base Info
- Model NO.：9 inch Slewing Drives
- Type：Single-Row Ball
- Size：9 Inch
- Warranty Period：1 Year
- Application：Material Handler
- Production Experience：Since Year 1993
- Rolling Body：Ball Bearings
- Separated：Unseparated
- The Number of Rows：Single
- Material：Bearing Steel
- Outer Dimension：From 3 Inch to 25 Inch
- Load Direction：Axial, Radial and Tilting Moment
- Transport Package：Wooden Box
- Specification：ISO9001: 2008
- Trademark：LYHY
- Origin：Luoyang, China
- HS Code：848210900
- Production Capacity：1000PCS,Month
Description
ModelRated output torque /KN-mTilting Moment torque /KN-mLoad /KNGear ratioSelf-locking gearsBoundary dimensions (mm)Weight (KG)Static load rating, axialStatic load rating,radialDynamic load rating, axialDynamic load rating,radialLL1L2L3H2H3H4ΦDΦD1ΦD2ΦD3ΦD4ΦD5n1-Yn1-XHH13"0.20.53016.69.68.462:1yes34615311480 14.560.5125100 100 1266-M106-M10190109125"0.30.87622.613.811.862:1yes36116812893.724.6738161135103.570501206-M107-M1021979187"113.513353322873:1yes398182166132.723.44.342.5237.5203.2163120.6981458-M1210-M1229581239"7.333.9338135817161:1yes546314239174.1294.454.5316270222.517514520416-M1615-M164111085012"9.254.347519011410078:1yes556324285220274.458.5401.5358308.525922928918-M1619-M16500110.56014"10.567.855522213311785:1yes547330303238283.559435.5390342.529526532518-M1623-M165301107317"14.5135.6975390235205102:1yes555338340275.3264.666522479.4425.5365.132440620-M1620-M1661512611021"20.22031598640385335125:1yes6784613983333.34.576616584.2525.5466.7431.853236-M2035-M20732136.515825"22.52712360945590470150:1Yes678461467401.86.24.578.2744675620585512628.536-M2035-M20863133.2230
