• Model NO.：X,B
• Type：Circular Gear
• Rated Power：0.37kw~55kw
• Gear Arrangement：Cycloid & Pin Wheel
• Ratio：9~1849
• Gearset：Cycloid Wheel & Pin Wheel
• Material：Cast Iron
• Manipulate Way：Semi-Automatic Manipulation
• Toothed Portion Shape：Bevel Wheel
• Changes Way：Stepped
• Manufacturing Method：Forging, Grinding
• Housing：Cast Iron
• Installation Method：Foot, Flange Mounted
• Shafts Position：in Line
• Max. Torque：150~20, 000n.M
• Housing Material：Cast Iron
• Input Form：Mounting Motor
• Transport Package：Wooden Case; Carton; Pallet
• Specification：ISO; CE; SGS
• Trademark：AOKMAN DRIVE
• Origin：China
• HS Code：8483409000
• Production Capacity：5000

Overview Product Description

Detailed Photos

Features:

1. Large reduction ratio, 1-stage ratio 9~87, 2-stage ratio 121~1849, larger reduction ratio is available by 3-stage or multistage combinations
2. High efficiency, the average efficiency is over 90%
3. Compact structure, light weight
4. Stable and reliable operation, low noise5. Long service life

Product Parameters

Parameters:

1 StageX2(B0/B12)0.37~1.59~87150Φ25(Φ30)Φ15X3(B1/B15)0.55~2.29~87250Φ35Φ18X4(B2/B18)0.75~4.09~87500Φ45Φ22X5(B3/B22)1.5~7.59~871,000Φ55Φ30X6(B4/B27)2.2~119~872,000Φ65(Φ70)Φ35X73.0~119~872,700Φ80Φ40X8(B5/B33)5.5~18.59~874,500Φ90Φ45X9(B6/B39)7.5~309~877,100Φ100Φ502 StageX32(B10)0.25~0.55121~1849-Φ35Φ15X42(B20/B1812)0.37~0.75121~1849-Φ45Φ15X53(B31/B2215)0.55~1.5121~1849-Φ55Φ18X63(B41/B2715)0.75~2.2121~1849-Φ65(Φ70)Φ18X64(B42/B2718)0.75~2.2121~1849-Φ65(Φ70)Φ22X741.1~3.0121~1849-Φ80Φ22X84(B52/B3318)1.5~4.0121~1849-Φ90Φ22X85(B53/B3322)2.2~5.5121~1849-Φ90Φ30X95(B63/B3922)3.0~7.5121~1849-Φ100Φ30X106(B74/B4527)4.0~11121~1849-Φ110Φ35X117(B84/B5527)4.0~15121~1849-Φ130Φ40(Φ35)

1 Stage Ratio: 9, 11, 17, 23, 29, 35, 43, 59, 71, 87
2 Stage Ratio: 121, 187, 289, 385, 473, 595, 731, 989, 1225, 1849

Installation:
Foot Mounted
Flange Mounted
Lubrication:

Foot-mountedFlange-mounted1 StageX2~X4X5~X11X2~X4X5~X11Grease LubricationOil-bath & Splash LubricationGrease LubricationOil Pump Circulation Lubrication2 StageX32~X42X53~X117X32~X42X53~X117Grease LubricationOil-bath & Splash LubricationGrease LubricationOil Pump Circulation Lubrication

Cooling:
Natural Cooling

Packaging & Shipping

Company Profile

Our Advantages

FAQ

1.Q:What kinds of gearbox can you produce for us?

A:Main products of our company: UDL series speed variator,RV series worm gear reducer, ATA series shaft mounted gearbox, X,B series gear reducer,
P series planetary gearbox and R, S, K, and F series helical-tooth reducer, more
than one hundred models and thousands of specifications
2.Q:Can you make as per custom drawing?
A: Yes, we offer customized service for customers.
3.Q:What is your terms of payment ?
A: 30% Advance payment by T/T after signing the contract.70% before delivery
4.Q:What is your MOQ?
A: 1 Set

Welcome to contact us for more detail information and inquiry.
If you have specific parameters and requirement for our gearbox, customization is available.
