2 Post Inground Lift (AA-IG3500C)

Dongguan Jiacheng Packing Material Co., Ltd
  • Type：One Cylinder Hydraulic Lift
  • Lifting Capacity：3.5T
  • Driving Type：Hydraulic
  • Certification：CE
  • Driving Motor Number of Mechanical Lift：1
  • Double Cylinder Lift Type：Planer-type

Base Info

  • Model NO.：AA-IG3500C
  • Shearing Lift Type：Big Shear Type
  • Condition：New
  • Design：Two Post
  • Max. Lifting Capacity：3500 Kg
  • Max. Lifting Height：1850 Mm
  • Full Lifting (Lowering) Time：40-60 Sec
  • Supply Voltage：AC380V,50Hz
  • Motor Speed：2870 Rounds,Minute
  • Transport Package：Metal Frame
  • Specification：CE
  • Trademark：AA4C
  • Origin：China
  • HS Code：8425429000
  • Production Capacity：1000units,Month

Description

Basic Info.

Model NO. AA-IG3500C Shearing Lift Type Big Shear Type Condition New Design Two Post Max. Lifting Capacity 3500 Kg Max. Lifting Height 1850 Mm Full Lifting (Lowering) Time 40-60 Sec Supply Voltage AC380V/50Hz Motor Speed 2870 Rounds/Minute Transport Package Metal Frame Specification CE Trademark AA4C Origin China HS Code 8425429000 Production Capacity 1000units/Month

Product Description

2 Post Inground Lift (AA-IG3500C)Max. Lifting capacity2 Post Inground Lift (AA-IG3500C)2 Post Inground Lift (AA-IG3500C)2 Post Inground Lift (AA-IG3500C)2 Post Inground Lift (AA-IG3500C)3500 kg
Load sharingMax. 6: 4 in or against drive-on direction
Max. Lifting height1850 mm

Max. Lifting capacity: 3500 kg
Load sharing: Max. 6: 4 in or against drive-on direction
Max. Lifting height: 1850 mm
Full Lifting (lowering) time: 40-60 sec
Supply voltage: AC380V/50Hz
Power: 3 Kw
Motor speed: 2870 rounds/minute
Output of oil pump: 4ml/r
Set pressure of the overflow valve: 130 bar
Solenoid valve voltage: AC220V/50~60Hz
Voltage of Electromagnet on mechanical lock:
AC220V/50~60Hz
Net weight: 1350kg
Main body length: 1650mm
Main body width: 430mm
Main body height: 2290mm
Sound level (measured at control console): ≤ 75 dBA
