• Model NO.：GX
• Type：Planetary Gear Reducer
• Rated Power：0.24~110 Kw
• Output Torque：Top to 108100
• Ratio：3-200
• Output Speed：22-2600rpm
• Heat Treatment：Carburising,Quenching,Gear Grinding
• Certificate：CCC,Cqm,Supplier Assessment
• Color：According to Customer′s Request
• Transport Package：Plywood
• Origin：Jiangsu
• HS Code：8483409000
• Production Capacity：400 Set,Sets Per Week

Basic Info.

Model NO. GX Type Planetary Gear Reducer Rated Power 0.24~110 Kw Output Torque Top to 108100 Ratio 3-200 Output Speed 22-2600rpm Heat Treatment Carburising/Quenching/Gear Grinding Certificate CCC,Cqm,Supplier Assessment Color According to Customer′s Request Transport Package Plywood Origin Jiangsu HS Code 8483409000 Production Capacity 400 Set/Sets Per Week

Product Description

GX Series Planetary Gearbox

GX series planetary gearboxes total specifications size are 9 ~ 36 ,
using highly standard modular designed,
rated output torque from 22 to 2600 KNM ,
speed ratio from 25 to 4000,
and GR, GK, GS series combination can get greater speed ratio.


Model	Ratio	Input Speed (RPM)	Nominal Power (KW)	Nominal Output Torque (N.m)
GX2NAZ9...36	25, 28, 31.5, 35.5, 40	1500/1000/750	43-12934	22000-2600000
GX2LAZ9...36	31.5, 35.5, 40, 45, 50, 56, 63, 71, 80, 90, 100	1500/1000/750	17-2937	22000-1200000
GX2SAZ9...36	45, 50, 56, 63, 71, 80, 90, 100, 112, 125	1500/1000/750	6-6050	22000-2600000
GX2KAZ9...20	112, 125, 140, 160 ,180, 200, 225, 250, 280, 320, 360, 400, 450, 500, 560	1500/1000/750	1.5-498	22000-354000
GX3NAZ9...36	140, 160 ,180, 200, 225, 250, 280	1500/1000/750	2.7-1953	22000-1920000
GX3SAZ9...36	280, 320, 360, 400, 450, 500, 560, 630, 710, 800, 900	1500/1000/750	0.8-1480	22000-1920000
GX3KAZ9...36	560, 630, 710, 800, 900,1000,1120, 1250, 1400, 1600, 1800, 2000, 2240, 2500, 2800, 3150, 3550, 4000	1500/1000/750	0.4-342	22000-1200000

Planetary Gearboxes Process Technology

GX series gearbox adopts high strength ductile cast iron, inner gear ring directly as enclosure, with gas carburizing and quenching gears and shaft, and the fine grinding process, and the gear tooth profile modification and tooth helix modification. The main parts adopt 3 d design software, finite element analysis was carried on.
The complete machine is machined parts have been closely, and through carefully assembled. Compared with the domestic ordinary NGW planetary reducer with high loading capacity of per certain volume, low noise, long service life, etc.

Planetary Gearboxes Arrangement

GX series products are coaxial input, input bevel gear, helical gear, bevel gear, helical gear type; Output shaft form with lhe swelling plate hollow shaft, involute spline hollow shaft and solid shaft with flat key, involute spline solid shaft; Installations are installed horizontally, the vertical installation, torque arm.

FAQ

1. Payment Term: 30% T/T in advance+70% balance before shipment or total advance.

2. Working time: about 20 to 30 days from receive payment.

3. We accept customized products: as per your special requirement.

4. Guidelines for the Selection: Usually we can select one machine which is suitable for you with some informations from you,such as ratio/motor speed/mounting dimension/ out torque etc.
