Speed Reducer Inline Planetary Gearbox Gear Unit Application for Crusher
Hebei Zhouwo Trading Co., Ltd.- Application：Motor, Machinery, Marine, Agricultural Machinery, Industry
- Function：Distribution Power, Clutch, Change Drive Torque, Change Drive Direction, Speed Changing, Speed Reduction, Speed Increase
- Layout：Coaxial
- Hardness：Hardened
- Installation：Foot Mounted
- Step：Three-Step
Base Info
- Type：Circular Gear
- Diameter：up to 885mm
- Material：Cast Iron
- Manipulate Way：Robotics
- Manufacturing Method：Cut Gear
- Toothed Portion Shape：Spur Gear
- Advantage：Equivalent to Brevini Planetary Gear Reducer
- Transport Package：Plywooe Case or Steel Cage
- Specification：ISO9001: 2008
- Trademark：SGR
- Origin：China
- HS Code：8483409000
- Production Capacity：400PCS,Month
Description
Basic Info.
Type Circular Gear Diameter up to 885mm Material Cast Iron Manipulate Way Robotics Manufacturing Method Cut Gear Toothed Portion Shape Spur Gear Advantage Equivalent to Brevini Planetary Gear Reducer Transport Package Plywooe Case or Steel Cage Specification ISO9001: 2008 Trademark SGR Origin China HS Code 8483409000 Production Capacity 400PCS/MonthProduct Description
Speed Reducer Inline Planetary Gearbox Gear Unit Application For Crusher
Key feature:
- Planetary gearbox is produced by modular design, and can be combined according to client's request
- Involuted planetary gear design
- Nodular cast iron Housing to increase rigidity and antiknock
- Heavy duty bearing on low‐speed shaft, and can bear big radial load due to proportionate distribution of torque
- All gears are case hardened to get high surface hardness, which guarantee transmission efficiency and whole gearbox's life
- Planetary gearbox has 16 models for different torque range, and each model have 1‐5 reduction stages to achieve different ratios
- Ratio range: 3.15‐9000
- Input power: 0.25‐55KW
- Permit torque rang: ≤ 800000N. M
- Output speed: 0.425‐445 r/min
- Structure mode: Possibility of flange, foot, or shaft mounting solutions
- Wide and comprehensive range of N series for industrial applications
- Low speed shaft design: Cylindrical with key, splined, hollow with shrink disc or splined hollow shaft
- Rigid and precise nodular cast iron casing
- Low noise running, high manufacturing quality standard
- High and reliable performance, load capacity and low speed shaft bearing
N series planetary gearbox torque sheet with models
| Gear unit size | 200 | 201 | 240 | 241 | 280 | 281 | 353/354 | 355 | 400 | 401 |
| Normal output torque T2N[Nm] | 1500 | 2000 | 3500 | 4000 | 4300 | 7300 | 13000 | 16000 | 20000 | 23000 |
| Gear unit size | 428 | 429 | 445 | 446 | 510 | 542 | 543 | 695 | 810 | 885 |
| Normal output torque T2N[Nm] | 26000 | 30000 | 32000 | 43000 | 63000 | 75000 | 100000 | 150000 | 300000 | 420000 |
