Zs Series Hard Tooth Surface Triple Stage Cylindrical Gear Box

Dongguan Hongshun Furniture Accessories Co., Ltd.
  • Application：Industry
  • Hardness：Hardened
  • Type：Cylindrical Gear Box, Cylindrical
  • Gear：Hardened HRC55-62
  • Shaft：Parallel Shaft
  • Input Motor：4p ~ 6p (1500rpm~750rpm)

Base Info

  • Model NO.：ZSY250-22.4-I
  • Color：Grey, Blue, Yellow, Green, Orange
  • Material：Cast Iron
  • Manipulate Way：Robotics
  • Toothed Portion Shape：Bevel Wheel
  • Changes Way：Stepped
  • Manufacturing Method：Grinding Gear
  • Transport Package：Wooden Case,Plywood Case,Pallet
  • Specification：ISO9001: 2008
  • Origin：China
  • HS Code：8483409000
  • Production Capacity：53000 Sets,Month

Description

Size60, 180, 200, 224, 250, 280, 315, 355, 400, 450, 500, 560, 630, 710Ratio22.4; 25; 28; 31.5; 35.5; 40; 45; 50; 56; 63; 71; 80; 90; 100 The rotation speed of high speed shaftno more than 1500rpm.The circumferential velocity of gearno more than 20m/s.Ambient temperature-40~45ºC. Lubricant should be heated up to 0ºC before starting if the ambient temperature is below 0ºCDirectionclockwise and un-clockwise
Characteristics:
1.The gear is made of high strength low carbon alloy steel through carburization and quenching. The hardness of tooth surface may reach to HRC58-62. All gear adapts NC tooth grinding process, high in accuracy and good in contact performance;
2.High in transmission efficiency: single stage, more than 96.5%; double-stage, more than 93%; three-stage, more 90%;
3.Smooth and stable in run, low noise;
4.Compact, light, long life, high bearing capacity;
5.Easy to disassemble, inspect and assemble.


Aplication fields:
widely used in various low-speed transmissions, which are general basic parts of mechanical transmission.mainly:
metallurgy, mines, hoisting, transportation, cement, architecture, chemical, textile, printing and dyeing, pharmaceutical, etc....


FAQ
Q: What is your MOQ of this item?
A: 1pcs. For the first time cooperation, we accept trial sample order.

Q: What's your payment terms?
A: 30% T/T deposit, 70% balance before shipment or L/C at sight.

Q: What's the delivery time?
A: 30 days after receiving your L/C or T/T deposit.

Q: Can we used our own brand on motors ?
A: Sure, we can offer OEM service, manufacture with your authorized brand.

Q: How long is your warranty?
A: 12 months after receiving B/L.
