After-sales Service：Videocall, Online&Face to Face Training Acceptable
Warranty：14 Months
Structure：Vertical
Power Source：Pneumatic
Type：Simple Disassembly
Automatic：Semi-Automatic
Base Info
Model NO.：C9551M
Standard：Standard
Certification：CE
Condition：New
Product Name：Motorcycle Tire Changer
Working Pressure：8-10bar,117-145psi
Outside Clamping：10-22"
Inside Clamping：13-24"
Max. Wheel Width：3-15"
Max. Wheel Diameter：1040mm (41")
Bead Breaker Force：2500kg
Color：Customized Color Acceptable
Machine Weight：N.W:245kg G.W:270kg
Optional Specifications 1：Optional Different Kinds of Front Cover
Optional Specifications 2：Optional Different Kinds of Pneumatic Locking
Optional Specifications 3：Optional Different Kinds of Inflation Gun
Optional Extra Accessory1：Motorcycle Adaptor
Optional Extra Accessory2：Bead Blaster Function
Optional Extra Accessory3：Leverless System
Transport Package：Plywood
Specification：1160*900*1050mm
Trademark：YuanMech
Origin：Yingkou, Liaoning, China
HS Code：8479899990
Production Capacity：3000PCS,Month
Description
1. Why is filter-regulator (FRL) so important? It dry the air so there is no moisture inside pneumatic components. It lubricates the rubber seals to extend its service life. In general FRL is important to maintain long service life of the machine. 2. When working table doesn't turn, how to determine if the problem comes from gearbox, motor or switch? Disconnect belt and see if the motor can run properly. If not, test the motor itself to see clockwise rotation and anti-clockwise rotation. If motor running properly then the problem is the switch. We have trouble shooting in details, please contact us for more information. 3. When working table doesn't have needed power to clamp the rim, how to trouble shooting if the problem comes from table cylinder, turning air distributor or pedal valve? When the cylinder not strong enough, there could be air leaking. The leaking could be on the covers or internal piston. There is a systematic method to trouble shoot, please contact us if you are interested in how to trouble shoot.
