• Model NO.：P2.5
• System Operating Platform：Win XP,Win 2000
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP43
• Certification：CE, RoHS, CCC, FCC
• Cabinet Size：640 X480mm
• Cabinet Material：Die-Cast Aluminum
• LED Encapsulation：SMD2121
• Module Size：320X160 mm
• Transport Package：Flight Case or Wooden Case
• Specification：CE, FCC. ROHS, 3C
• Trademark：PRT
• Origin：Shenzhen
• HS Code：8528591090
• Production Capacity：1000sq. M,Month

P2.5 SMD2121 Indoor full Color LED Screen SpecificationPixel pitch2.5 mmPixel Configuration1R1G1BLED componentSMD2121 Size of module320x160mmResolution of module128 x 64 dotsSize of cabinet640mm x 480mm x 45mmResolution of cabinet256 x192 dotsMaterial of CabinetDie-casting AluminumWeight of Cabinet6.5KGSBrightness>1000cd/sq.mDensity160000dots/sq.mBest viewing angle160° /140°Pixel Configuration1R1G1BBest viewing distance2-30MMaximum power consumption<1000W/sq.mAverage power consumption450W/sq.mDriving method1/32 scanControl methodSynchronization /Asynchronization (wifi,4G)Gray scale65536Colors256*256*256Color temperature3200-9300kUniformity97%Working voltageAC220V/110V±10%Working temperature-20ºC~+50ºC±10%Working humidity10% ~ 90%MTBF10,000 hoursFrame frequence50/60HzRefresh frequence>3840HzIP gradeIP31Life Span100,000 hoursData transafer methodRJ45Pratical standardCCC  TUV-CE  ETL etc.Effectivce Communication
Distance(without relay)Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KMAccepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.Systems operating platformWINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development






Product Advantages:
High refresh rate: With NOVA control system,and high refresh MBI5124 IC.  MBI5153,ICN2153 etc, no scanning line when photographed,perfect display vision
High gray level: 256 RGB each, display 16.7M colors, vivid and perfect video effect.
High resolution: The most apparent features of the new generation of LED display.
Good color uniformity:With brand Nationstar or Kinglight LED lamps,
High Quality: CE, RoHs, FCC, IP65, ISO9001 passed + 72 Hours serious testing time.
Long life span: over100,000hours, warranty at least 2 years.
You need = We design: Provide Personal- Customized led offer.

Why choose PRT?

1. PRT is a professional manufacturer of LED display screens more than years. We have strong R&D team to ensure high end products with user-friendly design ,and often updated to meet different requests
2. Our prices are high competitive due to our large-scale procurement of raw material.  We can help you to win more orders if you are distributors.also the end users will also be satisfied with our quality and price.
3. We have CE, FCC and RoHs certifications to confirm the quality. our products have been sent out to more than 50 countries .We have rich experience in handling all problems when you import goods from China .
4. We have a wide variety of products for you to choose from P0.9mm to P10mm for indoor,and P2.6 to P16 for outdoor.All products are strictly tested before release to next process, and we test every LED screen 72 hours before delivery.
5. Our salesmen/saleswomen have gotten well training to provide customers with professional advice on specific projects. Processional engineers are on standby, can offer guidance, on site technical support as requested.
6. We offer 2-3 years warranty and life time maintenance .Even after warranty time expired , we will only charge material costs
